Coconut Shell Carbon Jet Mill

Coconut Shell Carbon Jet Mill thumbnail-1
Coconut Shell Carbon Jet Mill thumbnail-2
Coconut Shell Carbon Jet Mill thumbnail-3
Coconut Shell Carbon Jet Mill photo-1
Coconut Shell Carbon Jet Mill photo-2
Coconut Shell Carbon Jet Mill photo-3
US$ 5,000 - 80,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Grinder
Product Type:
Other, Coconut shell
Contact Supplier Request Quote Chat Now
Qingdao Shina Machinery Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Grinder
Product Type Other, Coconut shell
Place of Origin Shandong, China
Brand Name SHINA
Model Number QWJ
Voltage suitable for local voltage
Power(W) 3000-90000
Dimension(L*W*H) different
Weight different
Certification CE cerficated,ISO9001:2008
Warranty 18 Months
After-sales Service Provided Engineers available to service machinery overseas
Product Description

 Process:

Air Jet Mill consisting of fluid bed opposed jet mill with integrated turbo classifier(s) for highest applications               with best top cut and steep particle size distribution.

There are a variation of application as mainly:grinding,classifying,homogenisation,selective operation,drying,                   surface treatment,and many others.

The fluid bed opposed jet mill can be combined with single wheel classifiers or multi-wheel classifier.


Feature of Air Jet Mill:

- Fluidbed opposed jet principle

- Loss in weight system
- Products free of oversize
- Steep particle size distribution
- Multifunction

- Special nozzle configuration

-Cryogen, inert, hot gas solutions
- Laboratory system available
- Contamination free processing
- Integrated turbo classifier as single wheel or multi-wheel

Technical Data:

TECHNICAL DATE
                Parameters
Type
Product Fineness
D97: μm
Grinding Air
m3/min
Air Pressure
Mpa
Motor Output
KW
QWJ03
3~100
3
0.7~1.0
3
QWJ06
3~100
6
0.7~1.0
6
QWJ10
3~100
10
0.7~1.0
4
QWJ20
3~100
20
0.7~1.0
5.5/7.5
QWJ40
3~100
40
0.7~1.0
15
QWJ60
3~100
60
0.7~1.0
18.5
QWJ80
3~100
80
0.7~1.0
5.5*4/22
QWJ120
3~100
120
0.7~1.0
15*3
QWJ160
3~100
160
0.7~1.0
15*4
QWJ240
3~100
240
0.7~1.0
15*6
QWJ320
3~100
320
0.7~1.0
30*3

Note: 1. Capacity depends on material properties and final product fineness

             2. Product Fineness is adjustable according to different technical data

Layout
Kinds of Wheels

Wheels with different construction materials are used for different feed materials:

              Construction Material:

              Carbon Steel

              Construction Material:

              Stainless Steel

              Construction Material:

               Light alloy

              Construction Material:

              Ceramic

              Construction Material:

              Ceramic Blades

              Construction Material:

              Ceramic Coated

Application

1.Nonmetal ores:

Coarse whiting, light calcium, calcium oxide, kaolin, barite, mica, quartz, talc, wollastonite, bentonite, potassium feldspar, andalusite, brucite, montmorillonite,etc

2.Chemical materials:

alumina, aluminum hydroxide, magnesium oxide, magnesium hydroxide, zinc oxide, precipitated barium sulfate, flame retardants, fiber, etc

3.New materials:

functional ceramic material, high purity silicon materials, fluorescent powder, glass beads reflective material, electric light powder, etc...

4.Pharmaceutical and food:

traditional Chinese medicine (TCM) : angelica, green tea, and west shawl, salvia miltiorrhiza, ganoderma lucidum spore

5.Pesticides:

herbicides, fungicides, pesticides and wettability powder, mildew antibacterial agent, pyrazole insect flies, organism amidine, carbendazim, clotrimazole, probenazole, etc

6.Battery material:

cobalt acid lithium, manganese acid lithium, lithium iron phosphate, nickel and cobalt acid lithium cobalt, nickel manganese acid lithium

7.Super hard material:

silicon carbide (black, green), boron carbide, diamond, white corundum, zircon sand, zirconia, rare earth polishing materials, tungsten carbide,

8.Metal powder:

aluminum powder, copper powder, zinc powder, iron powder, tin powder, cobalt powder, nickel powder, tantalum, niobium powder,

9.Ceramic building materials:

Ultrafine cement, water, slag, fly ash, bituminous, gypsum, slag, quick lime, silica fume, glass powder, etc

10.Other materials:

fluorescent pigments, iron oxide red, chrome oxide green, phthalocyanine cobalt blue, zinc oxide, lithopone, benzidine orange, toluidine red, vermilion, mica titanium pearl pigment, dyes, fluorescent whitening agent, wax coal, clay, electronic waste, fir skin, moss, garbage, soap, wax, etc


Above information are for referrence, for more information, please do feel free to contact us at once!

Packing & Delivery

Packaging Solutions：

                 1. Nude Packing                             2. Wodden Box Packing                     3. Wooden Pallet


Delivery Photos (Parts)：

Customer Referrence

Name: Air Jet Mill QWJ10

Name of feed material: Chemical etc
Place: Turkey
Installation Time: Jan.. 2014

Name: Air jet Mill QWJ 20

Name of feed material: Polishing Powder
Place: VietNam
Installation Time: Feb. 2016

Name: Air Jet Mill QWJ40

Name of feed material: Talc
Place: Pakistan
Installation Time: March. 2008

Name: Air Jet Mill QWJ120

Name of feed material: Medicine
Place: Guangxi , China
Installation Time: Aug. 2014

Name: Air Jet Mill QWJ20

Name of feed material: Toner
Place: Shandong , China
Installation Time: Jan.. 2009

Name: Air Jet Mill QWJ60

Name of feed material: Food
Place: Korea
Installation Time: March. 2015

Name: Air Jet Mill QWJ20

Name of feed material: Rare earth Polishing Powder
Place: Taian , China
Installation Time: Sept.. 2010
