G-POWER Electrical Vehicle Battery Charger 150V 16A
- 2000 Piece / Pieces per Month
- Nanjing
- Credit Card
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | G-power | Model Number: | EC22 |
Product Description
G-POWER Electrical Vehicle Battery Charger 150V 16A
Specification
Product introduction:
EV on board charger realized to use the single phase AC charging for high capacity
Batteries of electric vehicles directly. It is an intelligent on board charger with small volume, low
Weight and high efficiency.
Highlights:
1, Compact design
2, Parallel connection suitable
3, Bridgeless interleaved ZVS PFC
4, Full bridge resonant LLC DC/DC converter
5, Stable digital control for constant output mode or constant voltage mode (programmable)
6, Mutual supervision by MCU and CPLD
7, Small volume
8, Low weight
9, Water cooling
1 Electric Performance Parameters:
Input parameters:
Rated Input Voltage | 220VAC~240VAC |
|
Input Voltage Range | 90VAC~290VAC | Voltage low than 180VAC or high than 264VAC, Linear power to half |
Working Frequency Range: | 50Hz±10Hz |
|
Power Factor: | >0.99 |
|
THD | <5% |
|
Working Environment Temperature Range | -30°C~75°C | Modules do not start lower than-30°C,ambient temperature more than 50°C Linear Power beginning,75°C limit to 0 W, more than 78°C power off. |
1.1.2 Input Protection:
| Protection Point | Recovery Point | Protection Note |
Over-voltage Protection | 300VAC±5V | 290VAC±5V | No output, Yellow Light on |
Low-voltage Protection | 80VAC±5V | 85VAC±5V | No output, Yellow Light on |
Long-term Resistance to over Voltage | 320VAC |
| Withstand voltage of 320VAC, No output, Yellow Light on |
1.2.1 Output Parameters:
| 60V Module | 72V Module | 150V Module | Note |
Output Voltage | 52.5VDC~72.5VDC | 63VDC~87VDC | 120VDC~180VDC | Output-voltage Accuracy ±1% |
Output-voltage Temperature coefficient(1/°C) | ≤±0.5‰ | ≤±0.5‰ | ≤±0.5‰ | ≤±0.5‰ |
Max. Output-current | 35A | 30A | 16A | Output-current Accuracy ±0.5A |
Dynamic Property | ≤±5% | ≤±5% |
| Comply with GR731 |
Output-Power | 2100W | 2160W | 2400w |
|
1.2.2 Output Protection
|
| Protection Note |
Short-circuit Protection | YES | No output, Yellow Light on |
Reverse-Polarity Protection | YES | No output, Yellow Light on |
Over-voltage Protection | YES | Three-times-Over-voltage of output end, No output, Yellow Light on |
Over-temperature Protection | YES | Module automatically power off when over-temperature conditions arising inside the module; Start to Output within the temperature falling normal |
1.2.3 Other Output Parameters:
|
| Note |
Automatically power off when fully chargerd | YES |
|
Power Off | YES |
|
LED indicating the charging condition | YES |
|
CPU Whole charging Controlling | YES |
|
Temperature Compensation | YES |
|
2 Charger Outside Dimension:
2.1 PCB size:260*125*37 mm
2.2 Charge dimension:290*130*44mm
2.3 Charger Weight:<2kg
3 Cooling Type:Air Cooling
4 Noise: <55dB
5 Safety Requirement: GB4943, EN60950
