Ceramic Pressure Sensor SMC1800 Pressure Send Module

Ceramic Pressure Sensor SMC1800 Pressure Send Module thumbnail-1
Ceramic Pressure Sensor SMC1800 Pressure Send Module thumbnail-2
Ceramic Pressure Sensor SMC1800 Pressure Send Module thumbnail-3
Ceramic Pressure Sensor SMC1800 Pressure Send Module photo-1
Ceramic Pressure Sensor SMC1800 Pressure Send Module photo-2
Ceramic Pressure Sensor SMC1800 Pressure Send Module photo-3
US$ 3.00 - 3.00 MOQ: 500 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Chongqing, China
Brand Name:
WS
Model Number:
SMC1800 pressure sensor
Contact Supplier Request Quote Chat Now
Chongqing Wholesea Commercial Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Chongqing, China
Brand Name WS
Model Number SMC1800 pressure sensor
Product Description
Ceramic pressure sensor SMC1800 pressure send module



Ceramic Piezoresistive Pressure Sensor



SMC1800

1.Appearance Dimensions: φ18.0×6.35 mm
2.Alternative scope:5 bar,10bar,16bar,20bar,25bar,30bar,40bar,50bar,100bar
3.Work voltage: 2-40V
4.Input and output impedance : 10KΩ
5.0 place Output : 0±0.1 mv/V
6. Output Sensitivity : 2-4mv/V Typical values 2±0.2 mv/V
7. Linear, hysteresis, repeatability : 0.1 %
8. Response time : <1mS
9. Using temperature :-55~150°C
10.The temperature drift :±0.01%FS/°C,±0.02%FS/°C
11.Security overload : 3 times the rated range (when sensitivity is the typical value)
12. Stability : Better than 0.15% FS / year
