High Quality Coreless Motor CL-0408 for Medical Equipment, Industrial Equipment

High Quality Coreless Motor CL-0408 for Medical Equipment, Industrial Equipment thumbnail-1
High Quality Coreless Motor CL-0408 for Medical Equipment, Industrial Equipment thumbnail-2
High Quality Coreless Motor CL-0408 for Medical Equipment, Industrial Equipment thumbnail-3
High Quality Coreless Motor CL-0408 for Medical Equipment, Industrial Equipment photo-1
High Quality Coreless Motor CL-0408 for Medical Equipment, Industrial Equipment photo-2
High Quality Coreless Motor CL-0408 for Medical Equipment, Industrial Equipment photo-3
Negotiable MOQ: 10000 Units (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
CLCZH
Model Number:
CL-0408
Contact Supplier Request Quote Chat Now
Guangdong Chaoli Motor Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shantou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name CLCZH
Model Number CL-0408
Usage Boat, Car, Electric Bicycle, Fan, Home Appliance, Other, Boat, Car, Electric Bicycle, Fan, Home Appliance, Medical equipment, Industrial equipment
Certification ROHS
Type Micro Motor
Torque 0.08gf.cm
Construction Permanent Magnet
Commutation Brush
Speed(RPM) 17500rpm
Continuous Current(A) 60mA
Output Power 0.15W
Voltage(V) 2.6V
Efficiency IE 3

High quality coreless motor CL-0408 for Medical equipment, Industrial equipment





Key Specifications/Special Features







  • Below are the specifications and structures of the product, for more information, please feel free to contact us
  • Furthermore, we provide customizable service of micro DC motor/generator, including consulting, design and manufacture services, all the products are made to your order
  • Special features/structure:
    • Motor type: PMDC coreless motor
    • Motor housing (D*F* L): Φ4*8mm
    • Housing material: SECD-O
    • Shaft (diameter): 0.7mm SUS304 steel (nickel coating)
    • Way of commutation: precious metal-brush
    • Structure: 2-pole stator and hollow cup type
    • Magnet type: Nd-Fe-B
    • Rotation: CW/CCW and reversible
    • Weight: 0.6g (approximate)
  • Options:
    • Length and shape for the extended shaft
    • EMI/EMC suppression
    • Gear, eccentric wheel or reducer Increased
    • Magnet type
    • Wire diameter and turn number
  • Key parameters/performance
  • Rated voltage: 2.6V DC
  • At no load:
    • Speed: 42000rpm
    • Current: 35mA
  • At maximum efficiency:
    • Speed: 17500rpm
    • Current: 60mA
    • Torque: 0.08gf.cm
    • Output: 0.15W
  • At stall:
    • Current: 0.113A (maximum)
    • Torque: 0.12gf.cm
    • This product is widely used in: medical equipment, industrial equipment, navigation models, electrical tool and household appliances
  • Our advantages:
    • Specialized manufacturer
    • Complete variety of products
    • Volume production ability
    • Reasonable pricing with high quality
    • Short leading time, customized service
    • Please send us inquiries table including specifications for the performance and structure requirements
