Eight Nozzles Liquid Filling Machine

Eight Nozzles Liquid Filling Machine photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage, Commodity
Packaging Type:
Bottles, Cans
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Beverage, Commodity
Packaging Type Bottles, Cans
Packaging Material Wood
Automatic Grade Automatic
Driven Type Electric
Place of Origin China
Brand Name JINPACK
Model Number JT-LF8
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Specifications

APPLICATION:
water,wine,edible oil,perfume,pesticide,syrup,vinegar and so on.
Suitable to various sizes of container, easy adj

1,According to luquid characteristic ,we use different material for  the piston ring of volumetric injection pump.

2,Inside of the pump is very easy to clean and sterilize.You can knock-down the pump structure to clean.

3,PLC control system,The frequency can be adjusted,high degree automation ,no bottle no fill.

4,This system structure has good sealing ,fine appearnce,convenient and fast installnation and adjustment.



THE TECHNICAL PARAMETER AS FOLLOWS





ITEMS JT-LF4 JT-LF6 JT-LF8 JT-LF12 JT-LF16
Filling nozzles 4 6 8 12 16
Filling range 20-5000ml 20-5000ml
Ideal filling range 20-100ml/50-250ml/100-500ml/200-1000ml/500-2500ml/1000-5000ml
Filling speed(100ml)bpm 30-40 40-60 60-70 70-100 90-120
Filling precision 20-1000ml:≤±1% 1000-5000ml:≤±0.5%
Air pressure range 0.4-0.6MPa
Air consumption 10m³/h 15m³/h 20m³/h 30m³/h 40m³/h
Power supply 220V 50/60Hz
Power consumption 0.75Kw 0.75Kw 1.2Kw 2.2Kw 2.2Kw
Single machine noise ≤50dB
Net weight 500Kg 900Kg 1100Kg 1500Kg 1700Kg
Overall dimension(mm) 2000*1000*2000 2000*1000*2000 2500*1000*2000 2500*1000*2000 3000*1200*2000
