FEATURES
1.Support 2ch Full D1 real time + 6ch Full CIF real time recording resolution.
2.Dual-stream design,network remote view effects and local recording effects
3.Parameters can be set separately,independently of each other.
4.Hexaplex operation simultaneously:Preview,recording,playback,backup,
network live,mobile phone view
5.Support Multiple channel playback (Support 8CH playback simultaneously, each
channel can be enlarge to full screen)
6.Support Network function:one IE browser centralized monitoring and CMS Software
for multiple DVR (up to 255 DVR simultaneously)
7.Recording playback support:Normal play,Speed play,Fast back play,Manual single-frame slow play
8.Supports Built-in free DDNS domain name, with Server address:
9.Support Mobile phone remote view by Symbian S60V3/V5;WindowsMobile;
10.Android system; phone;Blackberry
11.Support alarm triggered recording will send alerts matter to the designated email.
12.System auto recovery to power after power reconnected, and return to the pre-power-down state
SPECIFICATION
8 CH H.264 DVR AS-9108VS | |
|
Video Compression Format |
H.264 |
Video System |
NTSC / PAL |
Video Input/Output(BNC) |
8CH BNC input/1CH BNC output |
Audio Input/Output |
1CH audio input,1CH audio output(RCA) |
Maximum Recording Rate |
D1:704*480 pixels with 60 IPS /704*576 pixels with 50 IPS |
Image Quality Setting |
Supper Best,Well,Good,Medium,Normal and Bad |
Hard Disk Storage |
Support one SATA HDD, unlimited for the capacity |
Alarm Input/Output |
1CH alarm input,1CH alarm output |
Multiplex Operation |
Live display/record/playback/backup/network transmit |
Recording Mode |
Auto/Manual/Timer/Motion/Alarm |
Playback Mode |
Multiple slow and rapid play speeds,manual and single-frame |
Backup Device |
USB flash disk/USB remove HDD/Network |
Pre-alarm Recording |
Recording for 10 seconds before alarming |
Network Protocol |
TCP/IP,PPPOE ,DDNS ,FTP,UPNP,ARSP and NTP |
Ethernet remote view |
Support remote surveillance up to 10 users simultaneously |
VGA Interface |
YES ,support VGA and BNC can work at the same time |
Log record function |
YES |
Video Loss Detection |
YES |
Video Adjustable |
Hue /Saturation /Contrast /Brightness adjust |
PTZ Control |
YES ,built-in RS485 port,support 17 kinds protocols |
IR Remote control/USB Mouse |
YES |
Power Source |
DC 12V |
Size(mm) |
432(W) x 95(H) x 367(D) |
