Specifications
1.Hydraulic power tong2.API 7K
3.Applied in making-up, breaking out for well drilling, repairing
4.pipe range:23/8-133/8""
Hydraulic power tong
1) TQ series of casing Tongs are widely used for making up or breaking out pipes or casings diameters of 4"~20" ,The tong heads are designedopen type and can freely clamp and escape from the casing ,TQ Casing Tongs are safe ,reliable ,and easy to handle with high mobility .This series of tongs can be connected to computer comtrolling units and can serve as ideal well mechanical tool for surface operations in oil fields.National Invention Patent of the tong has been got .The tongs are designed and manufactured according to API Spec 7KSpecification for Drilling Equipment . TCS torque monitoring system can be mathed with drill well Power Tongs casing tong and oil pip Power tong and can be well made-up .The characteristics are as follows . -Record and save the ultimate data ,such as :torque ,number of ciccles ,torque/time of .circles,torque/time. curves,date,time,well-team number ,single and total length. -According to the torque and circle number it automatically control the making-up torque and the circle number.It sures each commected joint in the best condition.
2) ZQ Drill Pipe Power Tong( for 2-3/8"--8") is an ideal wellhead tool for oil drilling,widely applied in madding-up and breaking-out for well drilling and repairing on offshore and land.Ppen-throat design of the ZQ-series with high mobility allows escaping from drilling pipe freely .The tong is a combination of spinning tong and torque tong .It substitutes cathead,suspension tong and spinning rope in making-up and breaking-out.The Tongs are designed and manufactured according to API Spec7kSpecification for Drilling Equipment...
3) XYQ series tubing power tong is used for quick make-up /break-out in well service operations .The tong is equipped with hydraulic bacdup tong and use inner curved cam to clamp.
4) The wrench is the best replacement of the spinning rope (or chain). IT is applied for mechanized spinning operation in fidids of oil and mine .The applicable range of pipe diameter is wide ,and it can be arbitrary adjusted whenever necessary .There are two configurations for clamping apparatus:air tyre and air crylinder .It is designed and manufactured according to API Spec 7k Specification for Drilling Equipment.
