Small size for handbags X-ray machine XJ5335
Shenzhen Xinyuantong Electronics Co., Ltd. and Shenzhen GUARDSPIRIT Metal Detector R&D Center professionally develop, produce, sell, manage and service“GUARDSPIRIT” security products and its facilities. It is a high-end new technology enterprise. Shenzhen Xinyuantong Electronics Co., Ltd. was founded in July, 2000.The Registered brand “GUARDSPIRIT” has been well accepted in the market and the results have been tremendous. Due to the incessant efforts on research and development for 6 continuous years, we have been able to develop 21 different variants of metal detectors and 5 model x-ray baggage inspection machine. They are now on sale throughout the country, and the demand for exports has also gone up significantly year on year. Shenzhen Xinyuantong Electronics Co., Ltd has achieved the status of the leader in Security Equipment in China, and is clearly established as the Number One in the Walk-through Metal Detector and X-ray bagagge scanner segment.
Shenzhen Xinyuantong Electronics Co., Ltd products are mainly supply for Airports, Railway Stations, Places of Vital Installations, Theatres, Places of Recreation, Jails, Courtrooms, Highly Restricted Government Buildings, Large Corporate Houses and Factories, Places of Worship and all other zones where security is a key area of thrust.
China Well-known Trademark: GUARDSPIRIT
SPECIFICATION
Tunnel Size : 530(W)×350(H)mm
Conveyor Speed: 0.22m/s
Conveyor Max Load: 150 kg
Single inspection dosage: <1.01μGy
Leakage radiation: <0.06µGy/h
Wire Resolution: 40AWG
Steel Penetration: 43mm
Film Safety: For ISO 1600
X-RAY GENERATOR
Orientation: Upward
Tube Current: 0.2-1.25mA(adjustable)
Anode Voltage: 80-160KV(adjustable)
Angle: 80°
Generator cooling/working periods:
Sealed oil bath with forced air/100%
OPERATING ENVIRONMENT
Storage Temperature: -20oC to 60oC
Operating Temperature: 0oC to 45oC
Relative Humidity:
20 to 95% non-condensing
System Power: 220 VAC (±10%) 50±3HZ
Power wastage: 1.0 KW (Max)
Noise<55DB
X-RAY Sensor: L-shaped array detector, 24bit
Image Performance System:
Display: High-resolution 19 inch color LCD display
Color quality: 24-Bit real colors based on materials
Edge enhancement: Object contour edge is more distinct
Super image enhancement: Image detail is more distinct
High penetration display: Increase the contrast of bright area in image to make the area that is easy to penetrate appear more clearly
Low penetration display: Increase the contrast of dark area in image to make the area that is difficult to penetrate appear more clearly.
Magnifier: Partial magnifying function
Brightening/dimming: Increase/Decrease brightness of image
Image recurrence: Display the previous twenty images and process any one of them
Image restoration: Restore image to initial status
Image storage: Real-time store any image and process it in operation status
Multi-energy: High/low energy: Switch from high energy to low energy
Color material identification: Organic objects in orange, inorganic objects in blue, mixture in green
Assist to detect drug and explosive powder
Special features:
Network interface: Capable of connecting to LAN, and support multi-terminal check for baggage at same time
Safety ray: Ray is transmitted under automatic control, avoiding the error
One-key shutdown control: Just rotate the key to shut down the machine; it is safety, easy and convenient
Eagle eye: Capable of expediently observing the magnifying area
Self-diagnosis function: Give message automatically if malfunction for prompt maintenance
