Baggage X-ray scanner XJ6550 for airport/factory security,check guns and weapons
1.Picture of X-ray baggage inspection system
2.Specifications
General Specifications
Tunnel Size : 650(W)×500(H)mm
Conveyor Speed: 0.22m/s
Conveyor Max Load: 170 kg
Single inspection dosage: < 1.29μGy
Wire Resolution: 0.0787mm metal line
Steel Penetration: 38MM
Film Safety: For ISO 1600
X-RAY GENERATOR
Orientation: Upward
Tube Current:0.4~1.2MA(adjustable)
Anode Voltage:100~160KV(adjustable)
Angle:60°
Generator cooling/working periods:
Sealed oil bath with forced air/100%
OPERATING ENVIRONMENT
Storage Temperature: -20oC to 60oC
Operating Temperature:0oC to 45oC
Relative Humidity:
20 to 95% non-condensing
System Power:220 VAC (±10%) 50±3HZ
Power wastage:1.0 KW (Max)
Noise<65DB
X-RAY Sensor: L-shaped array detector 24bit
Multi-energy: High/low energy: Switch from high energy to low energy
Color material identification: Organic objects in orange, inorganic objects in blue, mixture in green
Assist to detect drug and explosive powder
Certificate
Exhibition & Project
2012 18TH African union summit meeting
2011 Universiade Shenzhen Metro
2010 Shanghai World Expo
