Help CenterUHMWPE Pipe for Mining Tailing
Related Products
Specifications
The characteristic of UHMWPE pipes for mine tailing:1.Anti-abrasion
2.Anti High-pressure
3.From Lubrication
4.Non-scaling
The characteristic of UHMWPE pipes for mine tailing:
Anti-abrasion: Under the same instance, the bulk lost is only the 1/7 of steel piper .
Anti High-pressure:It is applicable under the press 0.2Mpa-4.0Mpa.
Anti-corrosion:Because the solid structure,it can anti-corrosion very well.
From Lubrication:The abrasion is the least among all the pipes materials .Under the same stance,the press lost is only the steel pipes1/10,and is only the nylon 1/7.
Non-scaling:The internal wall is so slippery that the medium cant deposit on it..
Light Weight:The density is the 1/8 of the steel.it's easy to convey and install.
Available to connection: It's welded by flange or hoop. And it's convey and install.
Anti-aging: There is anti-ultraviolet radiation material in the pipes, May use above for 50 years under the burning hot sunlight.
Health&Safety:This kind of pipe is innocuity..
Size of UHMWPE pipe:
|
O.D. DN(mm) |
0.4MPa |
0.6MPa |
0.8MPa |
1MPa |
1.25MPa |
1.65MPa |
2.0MPa |
|
|
Thickness mm |
Thickness mm |
Thickness mm |
Thickness mm |
Thickness mm |
Thickness mm |
Thickness mm |
||
110 |
|
|
4.7 |
6.0 |
7.4 |
9.2 |
11.4 |
|
125 |
|
|
5.4 |
6.7 |
8.3 |
10.3 |
12.7 |
|
140 |
|
|
6.0 |
7.7 |
9.5 |
11.8 |
14.6 |
|
160 |
|
5.2 |
6.9 |
8.6 |
10.7 |
13.3 |
16.4 |
|
180 |
|
5.9 |
7.7 |
9.6 |
11.9 |
14.7 |
18.2 |
|
219 |
|
6.5 |
8.6 |
10.8 |
13.4 |
16.6 |
20.5 |
|
225 |
4.9 |
7.3 |
9.7 |
11.9 |
14.8 |
18.4 |
22.7 |
|
250 |
5.5 |
8.1 |
10.7 |
13.4 |
16.6 |
20.6 |
25.4 |
|
280 |
6.2 |
9.1 |
12.0 |
15.0 |
18.7 |
23.2 |
28.6 |
|
315 |
6.9 |
10.2 |
13.5 |
16.9 |
21.1 |
26.1 |
32.2 |
|
350 |
7.8 |
11.5 |
15.3 |
19.1 |
23.7 |
29.4 |
36.3 |
|
400 |
8.8 |
13.0 |
17.2 |
21.5 |
26.7 |
33.1 |
40.9 |
|
450 |
9.8 |
14.6 |
19.1 |
13.9 |
29.7 |
36.8 |
|
|
500 |
11.0 |
16.2 |
21.4 |
26.7 |
33.2 |
41.2 |
|
|
560 |
12.3 |
18.2 |
24.1 |
30.0 |
37.4 |
|
|
|
630 |
13.8 |
20.5 |
27.2 |
33.9 |
42.1 |
|
|
|
700 |
15.3 |
22.7 |
30.6 |
38.1 |
|
|
|
|
800 |
18.0 |
26.0 |
38.1 |
|
|
|
|
|
900 |
20.0 |
30.0 |
42.1 |
|
|
|
|
|
1000 |
22.0 |
33.0 |
|
|
|
|
|
