UHMWPE Pipe with Float

Specifications

UHMWPE Pipe with Float
1.I.D. 60mm-940mm
2.O.D. 300-2200mm
3. Length: 500-2500mm
4.>20 years professional manufacturer

UHMWPE Pipe with Float



What is Floater?

_{The hull of MDPE FLOATER is made from medium density polyethylene material with excellent flexibility, filled with high strength polyurethane foam inside. With reasonable structure and good performance, the MDPE floater becomes the ideal substitution of the traditional steel floater for the floating dredging pipes.}





Advantage and Features:





-- Maintenance free





-- Great reliability





-- High value of buoyancy per unit





-- Very quick assebly





-- Possible fast variation of reserve buoyancy





-- Easily stored



_{Specification Table}







Floater I.D. (mm)	Floater O.D.(mm)	Floater Length(mm)	Thickness of Plastic(mm)	Floater Buoyancy force(kg)
220	500	800	7	200
300	700	1200	7	420
375	1100	1100	7	920
414	1100	1200	8	1020
430	1200	1200	8	1200
480	1300	1300	8	1500
580	1400	1550	9	2219
630	1400	1700	11	2400
680	1480	1800	11.5	2930
730	1600	1900	12	3593
780	1600	2000	13	3800
830	1800	2000	14	4800
880	1800	2200	15	5140
940	2200	2500	16	8180







   Floater Specification (unit: mm)







Ship Type	Steel Dredging Pipe I.D	Floater OD	Floater I.D	Floater Length
Self-priming Vessel	Φ355	Φ1100	Φ355	Φ1100
Self-priming Vessel	Φ400	Φ1100	Φ400	Φ1200
200 m3/H	Φ400-420	Φ1310	Φ430	Φ1335
350 m3/H	Φ550-560	Φ1300	Φ576	Φ1400
Beaver 1600	Φ500	Φ1370	Φ522	Φ1400
Beaver 3800	Φ650	Φ1500	Φ680	Φ1800
8000 wring	Φ800	Φ1780	Φ840	Φ2000
