Walk Through Metal Detector Gate--2010 Shanghai World Expo Model

WALK THROUGH METAL DETECTOR

MODEL:XYT2101--LCD

Technical parameter

Electric current: AC85V~264V/50-60HZ

Power: <20W, low consume, low radiation

Net weight: 65KG

Workplace environment: -20°C~+50°C

Standard: GB15210-2003, CE

Door panel size: 2230*560*82 mm

Control unit case size: 700*380*180 mm

Characteristic & Function

• 5.7 inch LCD screen with Infrared remoter controller
• Adopt advanced digital signal processing control replaced traditional analog signal control, better stability.
• Friendly windows interface, both Chinese and English program, easy to operate.
• Program Self-diagnostic when power on, automatically checking left and right door panel, LED light and choose the best working frequency.
• Automatically count passengers and alarm times, keep alarm records for inquiry (up to 20000 records)
• Detecting Zones: Standard 8 zones. It can extend to 16,24 zones by separate left and right alarm
• Sensitivity adjustable: Each zone has 255 degree sensitivity level, three patterns: High, middle, Low for different requirements. Preset the metal size, weight, volume, location to exclude the coin, key, belt..
• Sound Alarm: 1-25s alarm time, 255 different sound volume and 12 tones for choose
• LED light alarm: LED bar graph on left and right door frame, visible alarm simultaneously to ascertain the layout of metal articles
• Lock and Password protection, only the authorized person can operate.
• Anti-interference function, using advanced interactive transmitting and receiving to avoid interference, frequency range from 4K-8K to avoid frequency interference
• 6 preset programs for security application versatility
• 2-4 hours Battery backup for option, the uninterruptible power protection system secure the parameters when power off.
• PVC material and Control unit on the top, waterproof, moisture-proof and cooler.

Application

Walk through metal detector XYT2101LCD is popular used in Airport, banks, Embassies, Jail, Entertainment places, Gymnasiums, Exhibition Center ..etc
