China Supplier Construction Material EPS Sandwich Wall Panel

FOB Price

USD $6.5 - $12.5 / Meter

100 Meters(Min.Order)

Supply Ability 20000 Meter / Meters per Month
Port Shanghai Ningbo
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China	Brand Name	Baosheng
Model Number	950	Panel Material	Metal
Type	Other, EPS Sandwich Panels, Polyurethane Sandwich Panels

Product Description

Specifications

China Supplier Construction Material EPS Sandwich Wall Panel
1.Wall and Cold room panel
2.Thermal and sound insulation

China Supplier Construction Material EPS Sandwich Wall Panel

1. Specifications of products

Product Name	China Supplier Construction Material EPS Sandwich Wall Panel
Steel Thickness	0.3mm-0.7mm
Panel Thikness	40mm,50mm,60mm,75mm,100mm
Panel Effective Width	950mm
Length	According to customer' s request, less than 12m
Materials	PPGI steel and EPS foam
Structure	three layers: (1)upper layer is color steel sheet, (2)the inner layer is EPS foam (3)the bottom layer is color steel sheet
EPS Foam Density	10-30kg/m3
Color of Steel Plates	All RAL color
Parts	Eccentric hook for easy connect one by one Film covering in order to protect the steel of panels
Character	Light in weight, heat insulation and waterproof,environmental
Usage	various roofs and walls referring to the coldroom,storages, and etc.

2. Detailes of products

1. Excellent behavior in the corrosive and moisture enviroment.

2. Thermally efficient rigid foam insulation used as the core material of sandwich panel. Excellent behavior in the corrosive and moisture enviroment.

3.Strong and light weight materials suitable for the construction as it's ease of installation and labor cost saving.

4. Excellent high temperature stablity and low temperature application

Is it fire resistant?	PU sandwich panel is fire resistant, but EPS is not.
Is it sound-proof?	Both of PU and EPS sandwich panel are sound - proof.
What is the density of the PU/EPS?	Normally EPS is 12kg/m3, and PU is 38kg/m3.
What thickness of the PU/EPS can you provide?	Typically are 50mm, 75mm, and 100mm of EPS sandwich panel, 40mm, 50mm, 60mm, 75mm and 100mm of PU sandwich panel.
What is the width of the sandwich panel?	EPS sandwich panel: 970mm for roof, and 950mm for wall. PU sandwich panel: 950mm and 1000mm for both roof and wall.
Is the PU injected or glued?	Glued
How to load would be most efficient?	Make the sandwich panel to be full length of the container.
How to pack?	In order to well loaded to save the space, normally it is without packing.
What is the delivery time?	15 days.

3. Appilacation

Contruction: sandwich panel for wall is referring to the Steel house, suburban housing, villa, kindergarten, model house for apartment, commercial building, remodeling of old structures, warehouse, steel structure house, workshop, work plant, airport, cold storage, mobile house, etc.

4. Product Show

5. Factory and Company Show
