Polyurethane(PU) Foam Color Coated Made Sandwich Panel/Top Quality External Wallboard

Specifications

Good Temp-Keeping & Heat Insulation
Easy to install

Polyurethane (PU) Sandwich panel
Sandwich panel looks like sandwich. Two external surfaces are made of powder-coated steel sheets. And insulation materials usually use EPS, XPS, PU, Rock wool, Paper honeycomb, Aluminum honeycomb etc.

Product features
The sandwich panels are new multi-purpose construction material.
1. Heat and sound insulation.
2. Temperature suitable for PU ranges from -200 centigrade to 150 centigrade.
3. Light weight,
4. Seismic resistance,
5. Anti-corrosion etc.
6. Energy conservation,
7. Environment protection,
8. economical,
9. Good structure,
10. easy to installation.
11. water-proof,
12. Good chemical resistance

Specification
1. External steel panel
Thickness: 0.4mm ~ 1.2 mm
Basic steel: galvanized steel, galvalume steel and stainless steel
Finish: Galvanized, Powder-coated with PE/HDP/PUDF, Stainless steel with brushed/mirrored.
2. Insulation material
Type: Polyurethane (PUF), Density: 36~40 kg/cum
3. Panel
Width (mm): 980, 1180(the effective width)
Thickness (mm):50/75/100/125/150/200(mm) other options are available under client’s request.
Length (mm): tailored as per client’s requirement due to continuous forming production.
Shape: Notch + Alum. Joint + Notch (Tongue & Groove type is also available)

Application
They are widely used in clean room as non-force bearing wall, roof and ceiling and as force bearing wall in single-storey prefabricated buildings. The major application demonstrates in the clean room system as partitions & ceilings.
The fields range from electronics to semi-conductor, pharmaceutical, bio-tech and food processing etc.

Packaging Detail : covered with plastic film on both sides

Delivery Detail:      15-20days

Established in 2002, Hangzhou Baosheng Metal Material Co., Ltd. is located in the hometown of steel structures: Xiaoshan District of Hangzhou City. Our company covers an area of 400,000 square meters and enjoys convenient water, railway and freeway transportation.

Our company is specialized in researching, designing, manufacturing and distributing different sorts of constructional metallic materials. Our products include steel structures, galvanized and color-coated steel plates, corrugated ... View detail
