Help CenterWCM1 Series Adjustable MCCB Solar Energy Moulded Cade Circuit Breaker With CE
Related Products
-
WNS Series Adjustable MCCB Moulded Case Leakage Protection Circuit Breaker With CEUS$ 23 - 350MOQ: 1 Piece -
WS Series Adjustable MCCB Moulded Case Leakage Protection Circuit Breaker With CEUS$ 12 - 200MOQ: 1 Piece
-
DZ47 1P 63A Manufacturer Mini Circuit Breaker,Over Under Voltage DIN Rail MCB Circuit Breaker With CE Quality ChoiceUS$ 1.8 - 3.5MOQ: 10 Pieces
-
10-30VDC/90-250VAC NPN/PNP/2 Wires With NO/NC/NO+NC Output Infrared Photoelectric Sensor , Photoelectric Switches Series G12US$ 4 - 8MOQ: 10 Pieces
-
G14 Series 10-30VDC/90-250VAC NPN/PNP/2 Wires With NO/NC/NO+NC Output Infrared Photoelectric Sensor , Photoelectric SwitchesUS$ 4 - 8MOQ: 10 Pieces
Moulded Case Circuit Breakers Frequency AC 50Hz /60Hz, rated voltage up to 690V, rated working current up to 630A.
Used for infrequently switch and starting of motor and for motor overload, short circuit and under-voltage protections.Small volume, high breaking capacity, short over-arcing (some of specification is zeroarcing), strong anti-vibration
In accordance with the ultimate short circuit breaking capacity classified into four types: Type C (basic),Type L (standard),Type M (middle), Type H (high).
| Type | Rated current (A) | Num-ber of Poles |
Rated insul- ation voltage (V) |
Arcing-Over Distance (mm) |
Ultimated short Circuit Breaking Capacity (KA) |
Service Short Circuit Breaking Capacity (KA) |
Operation performa-nce | |
| ON | OFF | |||||||
| WCM1-63L |
6,10,16,20,25, 32,40, 50,63 |
3P, 4P | 660V | 480V | 0 | 25 | 1500 | 8500 |
| WCM163M | 0 | 50 | ||||||
| WCM1-100C |
6,10,16,20,25, 32,40,50,63, 80, 100 |
0 | 25 | |||||
| WCM1-100L | 0( ≤50) | 35 | ||||||
| WCM1-100M | 0( ≤50) | 50 | ||||||
| WCM1-100H | 0( ≤50) | 85 | ||||||
| WCM1-225C |
100,125, 160,180, 200 |
≤50 | 25 | 1000 | 7000 | |||
| WCM1-225L | ≤50 | 35 | ||||||
| WCM1-225M | ≤50 | 50 | ||||||
| WCM1-225H | ≤50 | 85 | ||||||
| WCM1-400C |
225,250, 315,350, 400 |
≤50 | 35 | 1000 | 4000 | |||
| WCM1-400L | ≤50 | 50 | ||||||
| WCM1-400M | ≤50 | 65 | ||||||
| WCM1-630C |
400, 500, 630 |
≤100 | 35 | |||||
| WCM1-630L | ≤100 | 50 | ||||||
| WCM1-630M | ≤100 | 65 | ||||||
| WCM1-630H | ≤100 | 100 | ||||||
| WCM1-800M | 630,700,800 | ≤100 | 65 | |||||
| WCM1-800H | ≤100 |
100 |
||||||
|
Q 1. what's the payment term? A. We accept TT,30% deposit and 70% balance agaisnt copy of BL Q 2. how's the delivery time ? A. usually it will take about 10 days for production Q 3. tell me the standard of package? A. Export standard carton box
Q 4.Could you offer Form A or C/O ? A. It totally not a problem. We can prepare relative documents to forgin affairs office or other office to apply for this certificate. Q 5.Would you accept to use our logo ? A.If you have good quantity,it absolute no problem to do OEM. Q 6.We want to know month capacity. A. It depends on which model.For example for 100A, month capacity can reach near 20000pcs. Q 7.Where is your market? A. Our products are popular in Russia, Indonisia, Philippines,Italy, America, Brazil and so on.Some of them are our regular customers and some of them are developing. We hope you can join us and make mutural benifit from our cooperation. |
“Facts speak louder than words”. For more informations, Inquiry NOW !!!
