Place of Origin Sichuan, China
Brand Name Leetro
Model Number P-80
Input Voltage AC220V
Output Voltage DC35KV
Output Power max. 80W
Output Frequency high frequency pulse or low ripple DC
Output Current max. 28mA
Product Description



* Introduction

This power supply is exclusively designed for CO2 laser machine. The output current can be set by user within the max one.



* Specifications:

Working

Environment Condition

Temperature

-10 ~ +40 °C

Moisture

≤85%

Output

Voltage

Max DC35KV

Current

DC (0~28) mA

Input

L, N and PE Wires, 50Hz 220V±10%

Accuracy

2%

Efficiency

95%

Protected Current

28±1mA

Response Time

0.2 ms

Switch

O and 1, TTL

Power Adjustment

0~5V analog or PWM signal

Size

245×185×100 mm

Weight

Net 3.1 Kg, Gross 3.5Kg



* Wirings

-         Connect the RED wire to the laser tube positive end

-         Connect the BLACK wire to the laser tube negative end

-         Details refer to the Port Definition diagrams

* Caution

-        Keep minimum 100 mm clear space out of the cooling fan!

-        Be careful with GND connection for the laser machine!

-        Must connect the RED wire to the laser tube positive end before power on!

-        Must connect the Neutral wire. Three-end plug should be applied with FG≤10Ω



* The Port Definitions

Port

Definition



Port

Definition

5V

Internal +5V



H

Active-high

IN

Power Control, 0~5V analog or PWM



AC/L

Live Wire

G

Working Ground



AC/N

Working Neutral wire

P

Water Protection Switch



FG

Grounding for Safety

L

Active-low
