HRM1900M Vertical Mill Used in Cement Plant

HRM1900M Vertical Mill Used in Cement Plant thumbnail-1
HRM1900M Vertical Mill Used in Cement Plant photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Production Capacity:
300 days per year
Place of Origin:
Jiangsu, China
Contact Supplier Request Quote Chat Now
Jiangsu Pengfei Group Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Production Capacity 300 days per year
Place of Origin Jiangsu, China
Brand Name Pengfei
Model Number vertical mill
Voltage 10KV
Power(W) 400KW
Dimension(L*W*H) 1900x1500mm
Weight Confirm
Certification CE, ISO9001
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Our vertical mill contains crushing, drying, grinding and grading conveying to apply to cement, metallurgy an chemical industry.



HRM1900M vertical mill technical parameter

  1. grinding disc diameter: φ1900mm
  2. grinding roller diameter: φ1500mm
  3. grinding disc rotating speed: ~34.7rpm
  4. main motor: YRKK450-6 400Kw ,10000v 50HZ IP54
  5. output: ≥26~35T/H (RO.08≤12%) (HG≥55)
  6. Max. feed size ≤40mm
  7. motor (separator) type: Y2-28OM-8 45Kw ,IP54
  8. separator rotating speed: 50~260r/min
  9. inlet temperature ≤300°C
  10. outlet temperature ≤80°C~95°C
  11.  inlet material moisture ≤12%
  12. outlet material moisture ≤1%
  13. air volume: ~85000m3/h
  14. pressure drop: 5.0~5.5Kpa
  15. hydraulic system pressure: 8~12Mpa
  16. reducer: ML40
  17. thin oil station type:XYZ-200
  18. hydraulic station type: HY17-22



Scope of supply of HRM1900M vertical mill



No.

Name

Specification and material

Qty.

I

Grinding roller device

Assembling part

2

1

Grinding roller shaft

40Cr

2

2

Roller core

QT40-17

2

3

Roller sleeve

High chromium cast iron

2

II

Transmission arm

Assembling part

2

1

Rocker arm

2G270- 500

2

2

Swing arm

2G270- 500

4

3

Shaft

45

2

III

Grinding disc device

Assembling part

1

1

Disc base

2G270- 500

1

2

Lining plate

High chromium cast iron

8

IV

Pressure device

Assembling part

2

1

Main oil cylinder

Assembling part

2

2

Subsidiary oil cylinder

Assembling part

2

V

Separating device

Assembling part

1

1

Rotor

Welding part

1

2

Rotor shaft

45

1

3

Motor

Y2-280M-8

1

4

Shell

Welding part

1

VI

Driving device

Assembling part

1

1

Main motor

YRKK450-6,400KW

1

2

Main reducer

ML40

1

3

Coupling and base

set

1

VII

Middle shell part

Welding part

1

VIII

Lower shell part

Welding part

1

IX

Reducer thin oil station

XYZ-200

1

X

High pressure oil station

HY17-22

1

XI

Electric control

set

1

XII

Coupling bolt, foundation bolt

set

1















































































































Company Introductin



Jiangsu Pengfei Group Co., Ltd covers an area of 350,000m2 and it has 0.82 billion RMB of total assets. It has six subsidiary companies such as the mechanical plant, electronic plant, casting plant, installation plant, the new type building materials plant, etc. Pengfei Group has the ability of supplying 6m rotary kiln, ball mill for cement production line with daily capacity of less than 10000tons, full set of compound fertilizer equipments with annual capacity of 500,000tons and active lime production line with daily capacity of leas than 1000tons.



Our company pursues product quality ceaselessly, cooperates with National Building Material Design Institute, and gradually develops new technology and new product. 11 products have passed the provincial identification, 6 products are approved to be national new products, 5 products gained provincial high quality product certificate, 4 products have been awarded high & new technical product certificate as well as 35 patents. Our main products are Pengfei Brand rotary kiln, ball mill, crusher, cooler, conditioning tower, dust filter, vertical kiln, roller mill, dryer, cement mechanical equipments, electrical controlling equipment and so on.
