bearing bush used in ball mill
Product Description
1. Specification: 2.6m
2. Model: MGX2613
3. Production capacity: 12-14t/h ( open circuit, OPC cement, Feed size: =0.5%,
Fineness of finished product: =450m2/kg, Wind speed in mill,1-1.2m/s)
4. Rotary speed of mill: 20.6 r/min
5. Charging capacity of grinding medium: 81t ( max )
6. Main motor ( Jiangsu Motor Plant )
Model : YR1000-8/1180
Power: 1000kw
Voltage: 6000v
7. Main reducer: MBY800 i=6.3333
8. Auxiliary motor
Model: YEJ200L-8
Power: 15kw
Rotary speed:730 r/min
9. Auxiliary reducer:
Model: ZSY250-?
Speed ratio: i=100
10. Cooling method: Water cooling
Jiangsu Pengfei could not only manufacture the spare part of rotary kiln with different diameters, but also the rotary kiln, globe mill, crusher, cooler, preheater, etc.
Company Information
The advantage of the position
Pengfei group has the important location, and it is the largest production & export base of large size rotary equipment in China’s coastal area. The advantage of the position: Jiangsu Pengfei Group Co., Ltd locates the main transportation county in the middle of Jiangsu province Haian county. It takes two hours from the company to the international cosmopolis Shanghai City. The international Nantong port and Shanghai port which locates in the Yangtse River Estuary make the large sized equipment export from our company very convenient.
Scope of business
1, It has the great comprehensive ability to provide best quality service on turn-key basis with technology design, complete plant, erection and debugging, commissioning for the new type dry process rotary kiln cement production enterprise under the daily capacity of 10000T.
2, It supplies complete equipments and technical services of grinding, calcination, oil extraction, crushing, dust collecting, conveying and lifting for the metallurgy, the chemical industry, the electrical power, the mine, the coal, the oil, the environmental protection enterprises, etc.
The products covering
The total amount in the cement machinery industry is second rank among the same business and top rank in Jiangsu. The products have been sold well all over the country and exported to more than 40 countries and areas such as Germany, Russia, Japan, Korea, Brazil, Egypt, Iran, Bangladesh, Pakistan, Turkey, Myanmar, Vietnam, Columbia, South America, etc.
General introduction of the company
The company has the six subsidiary companies such as the mechanical plant, installation plant, electronic plant, casting plant, installation plant, the new type construction material plant, etc. it covers an area of 350000m2 , and has 0.82billion RMB of total assets. There are 1500 personnel and 450 engineers and technicians, the annual manufacturing capacity reaches 300000t. Pengfei has already reached the capacity to manufacture 400 sets of large ball mills, 300 sets of roller press, 260 sets of pre grinding equipments and 150 sets of large rotary kiln per year.
Many thanks for your enquiry and would submit with pleasure in private order.
JiangSu Pengfei Group Co.,Ltd
contact preson(sales manager):Sally Wang
tel:+8615962769091
skype:wang.sally98
whatsapp:+8615962769091
Cement complete sets of equipment production export base
Quality control
Certificate
Delivery
