Help CenterPFG120-45 Roller Press Used in Cement Plant
Related Products
Rolling Machine
Rolling machine produced by Jiangsu Pengfei Group Co., Ltd is a new type of energy saving grinding equipment for cement.
Its grinding system integrates the rolling, scattering, separating, drying and powder separating into one body. Besides, when used together with a ball mill, it can be used in various process flows, like pre-grinding, mixing, semi-finished grinding, finished grinding and so on.
Due to the change in its grinding principles, this rolling machine and its grinding system have more advantages, like 50-100% lower power consumption, and 100-300% higher productivity.
Technical Parameters
1. Name: PFG120-45 Rolling Machine
2. Material name: raw meal of cement, clinker and so on
3. Total moisture content: ≤1-1.5%
4. Maximum feeding size: ≤70mm
5. Average feeding size: ≤25mm
6. Discharge size: more than 25% of processed materials are 0.08mm
7. Productivity: 100-140t/h
8. Operation mode: continuous
9. Power supply mode: voltage: 380V; motor model: Y355L-8
10. Layout mode: 2×220KW power for indoor motor
11. Roller diameter: 1200mm
12. Roller width: 450mm
13. Linear velocity: 1.48m/s
14. Max. crushing capacity of rollers: 70KN/cm
Company Introduction
Established in 1994, Jiangsu Pengfei Group Co., Ltd is a professional manufacturer of rolling machine in China. Besides rolling machine, we also provide customers with scatter grader, powder separator, cement production line, cement grinding plant, industrial kiln and furnace, grinding equipment, crushing equipment, environmental protection equipment, cooling equipment, drying equipment, compound fertilizer equipment, packing machine, chemical equipment and electrical control system. With the certifications of ISO9000 and CE, our products have been well received by customers from more than 60 countries and districts such as Germany, Russia, Brazil, Egypt, Iran, Japan, South Korea, Bengal, Pakistan, Turkey, Burma, Vietnam, South Africa, Columbia, Bolivia etc.
If you're interested in our rolling machine, please contact me freely.
