The Latest Technology,electronic t8 Led Tube,led Factory Lighting

The Latest Technology,electronic t8 Led Tube,led Factory Lighting photo-1
US$ 5 - 8.23 MOQ: 100 Pieces
Key Specifications
Get Latest Price
LED Light Source:
t8 led
Warranty(Years):
3
Input Voltage(V):
110~220V
Payment & Shipping
Payment Methods:
Port of Shipment:
Jiangmen/Shenzhen/Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
LED Light Source t8 led
Warranty(Years) 3
Input Voltage(V) 110~220V
Lamp Power(W) 21.5
Lamp Luminous Flux(lm) 1300-1500
Color Temperature(CCT) Other, 2700-6500K
Working Lifetime(Hour) 30000
Lamp Body Material Other, PC+aluminium
IP Rating Other
Certification CE, SAA
Place of Origin Guangdong, China
Brand Name OGJG
Model Number T8

The latest technology,electronic t8 led tube, led factory lighting

New Product!!!

Electornic T8 LED Tube (Replace T8 Fluorescent Tube Using on Electronic Ballast Directly)





feature:



1.The latest LED technology for converting ordinary fluorescent lamps internationally , simple structure, interchange between fluorescent lamp and led tube, can matched high class T8 electronic ballast



2.T8 electronic ballast bracket can be used to avoid a waste of resources, energy saving and environmental protection.



3.Using low Lumens depreciationLED chips, low Lumens depreciation, long life span.



4.Start quickly, no need to distinguish positive pole and negative pole, use drive circuit with high efficiency and constant current, no noise, no strobe and stable working .



Notes:

1.AC110V~220V is not allowed to light up LED lamp directly.

2.IC electronic ballast (integrated circuit electronic ballasts) can not be used, would lead to protection.

3.can not replace T8 magnetic ballast fixture.(T8 magnetic ballast type use OG-T8LED(DG) series.





 Specification

t8 led tube model

DC

(A)

lamp bead

luminous flux

LM led Qty.

lamp

bead

classification

Ra

life

span(H)

color temp tube size packing size

certified isolated

driver

OG-T8LED(DZ)-21.5w 0.23 20-25 1300-1500 176 3014 70 30000 2700-6500 1200x26x31 1245x220x170
OG-T8LED(DZ)-15w 1250-1450 132 900x26x31 935x220x170
OG-T8LED(DZ)-10.5w 600-750 88 635x26x31 635x220x170
