Help CenterAlcohol Distilling Tower
Related Products
Alcohol recovery tower is composed of tower reactor, tower body, condenser, chiller, buffer tank and high-order position storage tank. It is suitable to alcohol recovery for pharmaceutical, food and chemical industry and etc. The parts which contact material all made by 0Cr18Ni9 stainless steel with good decay resistance and could be used for a long time.
Item |
HC200 |
HC300 |
HC400 |
HC500 |
HC600 |
HC800 |
kettle volume (L) |
1000 |
1500 |
2000 |
2500 |
2500 |
3000 |
Height(mm) |
6000 |
7000 |
7000 |
7000 |
7500 |
7500 |
Volume of high level tank (L) |
1000 |
1000 |
2000 |
2000 |
2000 |
2500 |
Condensation area (m2) |
5 |
9 |
11 |
18 |
25 |
45 |
Cooling area(m2) |
1 |
1.5 |
2.2 |
4 |
6 |
8 |
Heat transfer area(m2) |
3.0 |
6 |
6.5 |
10 |
15 |
26 |
Recycling ability(kg/h) |
45-50 |
90-110 |
150-160 |
280-300 |
430-450 |
600-650 |
Recycling concentration(%) |
>90 |
|||||
Packing type |
Stainless steel corrugated packing |
|||||
Weight(kg) |
1500 |
2200 |
3500 |
4000 |
4500 |
6800 |
Size: LxWxH(mm) |
2300x700x7300 |
2600x800x7500 |
2500x1000x9000 |
3000x1200x9000 |
3500x1400x10000 |
4200x1800x14000 |
For more details, please just contact us if you need.
