plastic blowing machine ZK-135B
- 30 Set / Sets per Month
- NINGBO SHANGHAI
- T/T
- High speed Plastic bottle making 0.5L- 2L 6000BPH Automatic PET bottle blow blowing mold molding machine prices
- Factory Price High Quality Automatic Fast Plastic PP HDPE Bottle Blowiing Jerrycan Extrusion Blow Molding Machine
- Semi Automatic PET Plastic Bottle 5 Gallon 20 Liter Blow Molding Machine Price
- custom design semi-automatic preform pet plastic bottle blowing blow molding machine high speed
- Semi-automatic Two Cavity Bottle Making Machine Blow Molding Equipment
- Plastic bottle blowing machine Beverage bottle blowing machine Medicine bottle blowing machine
Product Details
Condition: | New | Plastic Processed: | Other, PE, HDPE,PP,PC,ABS,PVC,XPS ETC | Blow Moulding Type: | Extrusion Blow Moulding |
Automatic: | Yes | Place of Origin: | Zhejiang, China | Brand Name: | shengda |
Model Number: | ZK-135 | Application: | Other, pipe, plate,board,toy,car parts |
Product Description
Specifications
plastic blowing machinesuit for drum, huge container,board,toy..
screw diameter:135mm
PLC+touch screen+MOOG
plastic blow molding machine
ZK-135B Model automatic large extrusion blow molding machine---This model adopts accumulator die. Parison programmer is available to control thickness.This model is automatic process with low noise, saving energy, high efficiency,safe operation, easy maintenance and other benefits. This model is widely used to produce chemical barrel, auto parts ( water box, oil box, air-condition pipe,aoto tail), toys(wheel,hollow autobike, basketball stands,baby castle), tool box,vacuum cleaner pipe, chairs for bus and gymnasium,etc.
Features:
1) Controlled by Japan mitsubishi PLC
2) Temperature controlled model
3) Interactive monitor with machine-human interface
4) Imported hydraulic elements
5) Proportional control
6) Imported electric elements
7) Hard gear surface reducer
8) Accumulator head with special steel
9) Vicker hydraulic valve, seal and proportional control
10) Japan mitsubishi PLC+ Taiwan human machine interface +software in touch type +famous brand electric elements.
following is the technical specifications:
specification | unit | zk-135B |
max container capacity | L | 500 |
number of die heads | set | 1 |
machine dimension(L*W*H) | M | 8*3.6*5.2 |
total weight | ton | 32 |
clamping unit |
|
|
clamping force | KN | 1800 |
clamping speed | m/min | 10 |
platen opening stroke | mm | 600-1600 |
platen size(W*H) | mm | 2000*1700 |
mould thickness | mm | 500-800 |
power |
|
|
max drive | KW | 30 |
total power | KW | 250 |
air pressure | Mpa | 1 |
air consumption | m3/min | 5 |
extruder unit |
|
|
screw diameter | mm | 135 |
screw L/D ratio | L/D | 28:1 |
plasticizing capacity | kg/hr | 320 |
number of heating zone | zone | 5 |
extruder heating power | KW | 30 |
extruder driving power | KW | 63/160 |
accumulator head |
|
|
number of heating zone | zone | 5 |
power of die heating | KW | 6 |
max die-pin diameter | mm | 750 |
accumulator volume | L | 50 |
