China Manufacturer RV Series Worm Gear Reducer NMRV Agricultural Bevel Gearbox
- Tianjin
- T/T
You May Like
-
China Manufacturer RV Series Worm Gear Reducer NMRV Speed Gearbox
-
China Manufacturer RV Series Worm Gear Reducer NMRV Transmission Gearbox
-
China Manufacturer RV Series Worm Gear Reducer NMRV Agricultural Gearbox
-
NMRV Professional Manufacturer of Aluminium Speed Reducer
-
NMRV Professional Manufacturer of Aluminium Worm Gear Motor
-
1:100 Ratio Speed Reductor Aluminum Alloy Motor Reductor
Product Details
| Place of Origin | China | Brand Name | WOSEN | |
| Model Number | NMRV | Gearing Arrangement | Worm | |
| Output Torque | Up to 650Nm | Rated Power | 0.18~7.5KW | |
| Input Speed | 1450RPM | Output Speed | 14~187r/min |
Product Description
Specifications
agricultural bevel gearbox1.Gearbox with excellent quality and competitive price
2.Aluminum casting gearbox
China Manufacturer RV Series Worm Gear Reducer NMRV
agricultural bevel gearbox
Characteristics:
(1) With excellent quality
(2) Reasonable price
(3) Promise to delivery on time
(4) Large output torque
(5) Safe, reliable, economical and durable
(6) Stable transmission, quiet operation
(7) High heat-radiating efficiency, high carrying ability
(8) Certificate of quality: ISO9001:2008
(9) Every product must be tested before sending
(10)Made of high-quality aluminium alloy, light weight and non-rusting
(11)Large output torque.
(12) Smooth running and low noice.
(13) High radiating efficiency.
(14)Good-looking appearance, durable service life and small volume.
(15) Suitable for omnibearing installution.
Output torque: Up to 650Nm
Output speed: 14~187r/min
Power of motor: 0.18~7.5KW
Mounting mode: foot mounting, flange mounting
| Type: | gearbox |
| Model: | Center Distance:25,30,40,50,63,75,90,110,130 |
| Ratio: | 5,7.5,10,15,20,25,30,40,50,60,80,100 |
| Color: | Blue/Silver White |
| Material: | Aluminium Alloy |
| Worm Gear- Cooper-10-3 | |
| Worm-20CrMnTi with carburizing and quenching, surface hardness is 56-62HRC | |
| Shaft-chromium steel-45 | |
| Packing: | Carton box/per set(With foam board inside) |
| Bearing: | Brand "NSK" Bearing |
| Seal: | NAK Seal from TAIWAN |
| Warranty: | 1 year |
| Input Power: | 0.1kw,0.55kw,0.75kw,1.1kw,1.5kw,2.2kw,4kw,5.5kw,7.5kw |
| Usages: | In industrial machine: widely used in packing, printing,textile machine,as well as woodworking,glass and plastics,food stuff,ceramics,chemical,etc. |
| IEC Flange: | B5,B14 |
| Lubricant: | Synthetic & Mineral |
1.Price: If the minimum order amount is in excess of $10000, there are preferential.
2.Payment Term: 30% TT in advance+70% balance before shipment or total advance.
3.Working time: about 20 to 30 days from receive payment.
4.We accept customized products: as per your special requirement.
5.Guidelines for the Selection: Usually we can select one machine which is suitable for you with some informations from you,such as ratio/motor speed/mounting dimension/ out torque etc.
