CNC Router Aluminum Brass Engraver Wood Working Mini Small Desktop Mould Engraving Machine 5040
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Anhui, China
Brand Name:
GOLDCUT
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Place of Origin
Anhui, China
Brand Name
GOLDCUT
Model Number
MD-5040
Rated Power
1-3KW
Engraving Speed
10m/min
Main Axle Rotational Speed
0-24000rpm/min
Feeding Height
250mm
Milling Cutter Diameter
3.175/4/6mm
Application
mould
Dimensions
500*400mm
Weight
300KGS
Certification
ISO CE ROHS BV
Warranty
one year warranty
After-sales Service Provided
Overseas service center available
Specifications
CNC router aluminum brass engraver wood working mini small desktop mould engraving machine 5040CE BV ROHS ISO
CNC router aluminum brass engraver wood working mini small desktop mould engraving machine 5040
Character features:
1. adopting casting structure for body, gantry, brackets features better rigidity.
2. fully-closed or semi-closed design.
3. imported rolling ball screw and linear square rail.
4. configured with high-precision and powerful spindle.
Technical parameters:
| model | MD-3020 | MD-5040 |
| processing area | 300*200 | 500*400 |
| Feeding height | 70mm | 250mm |
| Max Idle speed | 10m/min | 15m/min |
| Max processing speed | 5m/min | 10m/min |
| Transmission type | gear rack | |
| spindle power | 1kw inverter-driven constant power water cooling spindle motor | |
| rotating speed of spindle | 0-24000rpm/min | |
| working voltage | AC220V/50HZ | |
| engraving tool | ¢3.175/4/6mm | |
| file format | G Code/HPGL | |
| Positioning precision | ±0.02mm | |
| second time positioning precision | ±0.01mm | |
| controlling system | NC Studio PCIMC motion control system | |
| Software | compatible withType3/Artcam/Castmate/CAXA/UG/ Pro-E/Mastercam/Ucancam etc. | |
Application field:
mould for small and medium vehicle parts,plastic mould,pressing mould,high-frequency mould red copper electrode,black lead,shoes mould,plastic drop bronzing mould,jade engraving,jwwelry,stamp,crafts,processing various precise instruments.
