Specifications
Pit mechanical car parking system:1.Multiple protection device
2.4-point safety device
3.Independent car-resistant device
PSH Pit lift-sliding mechanical car parking system
1. Advantage and Application
(1) The system mainly uses chains to lift, often has 3 layers:1 layer underground and 2 layers on the ground, the max layers has 8 layers(3 layers underground, 5 layers on the ground).
(2) The entrance is on the first floor, utilizing big span design, well suitable for building under green square, residential building and office building.
(3) It is one equipment which can fully utilize the space underground.
2. Layout
Each group of controlling of this parking system is designed into 3-car to 10-car, the best is 8-car,
and it depends on specific site conditions.
3. Working Principle
The equipment uses chain to lift and utilizing big span in front or back side, each parking space with a car board, which through lifting up and down and sliding to the ground, the driver goes into the garage, parks or takes a car, finishes the whole procedure.
4. Equipment Type
4-point safety device on the ground and underground; independent car-resistant device, over-length, over-range, and over-time detection, crossing section protection, guiding and balancing equipments.
5. Technical Parameters
Name |
Instruction |
|||
Layer |
Upper layer |
Sliding layer |
Pit layer |
|
Vehicle Size |
Length |
5000(mm) |
5000(mm) |
5000(mm) |
Width |
1850(mm) |
1900(mm) |
1850(mm) |
|
Height |
1550(mm) |
1550(mm) |
1550(mm) |
|
Vehicle Weight |
1700(kg) |
2000(kg) |
1700(kg) |
|
Lifting |
Power |
2.2(kw) |
||
Speed |
2.5-4(m/min) |
|||
Sliding |
Power |
0.2(kw) |
||
Speed |
8(m/min) |
|||
Driven Mode |
Electric machine+Cycle chain |
|||
Operation Mode |
Button, Automatic, Manual |
|||
Power Supply |
AC380V/220V50Hz; 3¢380V/220V50Hz |
|||
