Brake Shoes Machine

Name: Brake Shoes Machine
Brand: Torch
SKU: 110841319
Availability: InStock

US$ 1 - 100,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Torch

Model Number:

A series

Zibo Battery Machine And Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao Port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name Torch

Model Number A series

Condition New

After-sales Service Provided Engineers available to service machinery overseas

Machine for Brake pads

RYS-A series

Structural characteristic

1. Adapts spring force mould sealing technology, it can effectively prevent the splith of the material in casting process and improve the brake pads quality.
2. Mould which is located outside of the four pillars for manual operation ensure the safety of the operators.
3. Upper mould adapts automatic clamping device , it is easy to replace and the mould replacing time is within 5mins.
4. Upper mould adapts automatic mould agent releasing, reduce the operators working intensity.
5. Multi-station machines can be arranged in Line or in circular.

Control characteristic:

1. Adapts Simens PLC control system and with Industrial Ethernet interface
2. 12” industrial panel computer shows the real-time running state of multi station machines
3. 6’ touch screen shows the real-time running state of the single station machine
4. Mould heating system is separately controlled by single station. It adapts PID temperature control ensure the temperature tolerance inside the mould cavity is within plus and minus 3 degree centigrade.
5. Pressing pressure gets feed back from the high precision pressure sensor, it is real time control. And the main cylinder pressure can be accurately controlled within Plus and minus 0.3Mpa
6. Oil pump motor stops in pressure keeping process and the accumulator helps to keep the pressure so energy saved

Machine characteristic:

1. Lower mould cost with modular design and compact structure
2. Can be widely used and meet the small and medium production capacity requirement
3. Small size and excellent appearance.

Product specification

type	Normal weight strength KN	Balance cylinder stroke mm	Mould locking strokemm	Main cylinder Stroke mm	Efficient working table size mm		Motor Power KW	Weight KG	Machine size MM
type	Normal weight strength KN	Balance cylinder stroke mm	Mould locking strokemm	Main cylinder Stroke mm	L R	FB	Motor Power KW	Weight KG	Machine size MM
100T	1000	15	280	420	600	540	5.5	3500	92014601950
150T	1500	15	280	420	630	560	7.5	4300	95015202210
200T	2000	20	280	420	700	650	11	4800	118016402400
