Home > Manufacturing & Processing Machinery > Lifting Equipment > Lifting Table > GTBZ32 Self-propelled Telescopic Boom Lift
GTBZ32 Self-propelled Telescopic Boom Lift
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
RUNSHARE
Model Number:
GTBZ32
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
GTBZ29 Self-propelled Telescopic Boom LiftNegotiableMOQ: 1 Set -
GTBZ24 Self-propelled Telescopic Boom LiftNegotiableMOQ: 1 Set
-
GTBZ20 Self-propelled Telescopic Boom LiftNegotiableMOQ: 1 Set
-
GTBZ22Z Self-propelled Telescopic Boom LiftNegotiableMOQ: 1 Set
-
GTBZ14 Self-propelled Telescopic Boom LiftNegotiableMOQ: 1 Set
Place of Origin
Hunan, China
Brand Name
RUNSHARE
Model Number
GTBZ32
Specifications
Automatic-leveling platform,Hydraulic platform rotation, 360 continuous turntable rotation,Fully proportional joystick controls
| Working height maximum * | 33.7m | 111ft | |
| Platform height maximum | 32m | 105ft | |
| Horizontal reach maximum ** | 24.4m | 80ft | |
| Below ground reach | 4.51m | 15ft | |
| A | Platform length-8ft model | 0.91m | 3ft |
| Platform length-6ft model | 0.76m | 2ft6in | |
| B | Platform width-8ft model | 2.44m | 8ft |
| Platform width -6ft model | 1.83m | 6ft | |
| C | Height-stowed | 3.08m | 10ft |
| D | Length-stowed | 14.02m | 46ft |
| E | Width –axle retracted | 2.49m | 8ft |
| Width –axle extended | 3.35m | 11ft | |
| F | Wheelbase | 3.66m | 12ft |
| G | Ground clearance-center | 0.43m | 1ft5in |
| PRODUCTIVITY | |||||
| Lift capacity (restricted) | 480kg | 1056lbs | 480kg | 1056lbs | |
| Lift capacity (non-restricted) | 340kg | 748lbs | 340kg | 748lbs | |
| Platform rotation | 160° | 160° | |||
| Jib rotation | — | 135° | |||
| Turntable Swing | 360°continuous | 360°continuous | |||
| Turntable tailswing -axle retracted | 1.82m | 6ft | 1.82m | 6ft | |
| Turntable tailswing -axle extended | 1.38m | 5ft | 1.38m | 5ft | |
| Travel speed -stowed | 4.4km/h | 2.73mph | 4.4km/h | 2.73mph | |
| Travel speed -raised or extended | 1.1km/h | 0.68mph | 1.1km/h | 0.68mph | |
| Gradeability -stowed (4WD/2WD) | 42%/30% | 42%/30% | |||
| inside | 4.14m | 13ft7in | 4.14m | 13ft7in | |
| Turning radius - axle retracted outside | 6.56m | 22ft | 6.56m | 22ft | |
| inside | 2.74m | 9ft | 2.74m | 9ft | |
| Turning radius - axle extendeded outside | 5.85m | 19ft | 5.85m | 19ft | |
| Controls | 24V DC Proportional | 24V DC Proportional | |||
| Solid tires | 12.00-20/8.5 | 12.00-20/8.5 | |||
