TENA tempered glass
Scientific principle |
Tempered glass, also known as toughened or reinforced glass, is made by annealed glass heated to its softening point and quickly cooled by air flow on the surface. After the tempering process, an uniform compression is formed over the glass surface while tensile stress formed inside the glass sheet. Thus both its mechanical strength & heat-stability are increased greatly compared to common glass sheet. |
Superior safety |
In case of being broken, TENA tempered glass sheet will change into thousands of tiny pieces without acute angles. Thus no injuries to the body of human beings can be caused. As shown by the two photos below.
Broken tempered glass Broken common glass |
High-impact performance |
TENA tempered glass can withstand the vertical hit of a 1 Kg steel ball falling freely from 1 meter height, and separately, the side hit by a 45 Kg ball of lead bullets from 1.2 meter height, without broken. Its performance is 5~10 times higher than that of ordinary flat glass sheets. |
Better heat-stability |
It can stand a heat-shock (sudden change of temperature) of 220~250 °C, while a common glass sheet of the same thickness can only stand 70~100 °C. |
Types of single sheet |
Clear transparent, tinted, colorful glazed, film coated, Low-E, etc. |
Types of combined sheets |
Laminated, insulated, etc. |
Test Reports |
Passed test of National Standard < GB 15763.2-2005, Safety glazing materials in building-Part 2: tempered glass> |
Applications |
TENA tempered glass sheet is a kind of safety glass meeting both high mechanical and safety requirements. Can be used on external/internal curtain walls, doors & windows, elevators, partitions, atrium, lighting roof, and other locations in buildings, such as hotel, shopping mall, museum, concert hall, theater, business center, airport, library, university, CBD area, banks, media center, hospital, apartments, etc. And can be used in furniture and home appliances as well. |
Building projects applied |
TENA products have been widely used successfully in hundreds of outstanding buildings, such as National Center for the Performing Arts (NCPA) in Beijing, Guangzhou International Finance Centre (IFC), Guangzhou Railway Station, 5-star Sheraton Dameisha Resort Hotel Shenzhen,etc. TENA products are winning the trust of more and more clients. |
Tempered glass of 15,19mm-Test Report
The testing results on the submitted samples of tempered glass used in buildings (Max size: 2440mm*3660mm, thick 15mm, 19mm respectively) are up to the requirements of related China National Standard (GB15763.2-2005, Safety glazing materials in building-Part 2: Tempered glass). These tempered glass sheets are suitable for curtain walls and other locations of buildings. The test report was issued by <National Glass Quality Supervision & Inspection Center>.
TENA CCC certificate (#2011011302491038 Certificate for China Compulsory Product Certification)
This CCC certificate (Certificate for China Compulsory Product Certification)
certifies qualification of, the quality assurance ability of the company
+ testing & inspection on the product model (of tempered glass used in buildings,
max size: 2440mm*3660mm, thick 15mm, 19mm respectively, are up to the requirements
of related China National Standard GB15763.2-2005, Safety glazing materials
in building-Part 2: Tempered glass) + randomly sampling, testing or inspection
on site after the CCC certificate is granted, in accordance with related CCC rules
(CNCA-04C-028:2009).
Manufacturing line for tempered curve glass
TENA understands deeply the operation principle of 6-key factors assuring product quality, the 3M2E1T formula (Employees, Machines, Materials, Method, Environments & Testing). Here shows some advanced manufacturing machines and testing facilities invested by TENA in its ISO9001-2008 certified factories. All these factors combined together make sure only qualified products up to high standards can be provided by TENA Group to customers.
TENA Group owns 14 national patents focusing on innovations with the honor of
<Certificate of High & New Tech Enterprise> granted by the government.
TENA patent: A kind of fixed heating furnace to temper glass
TENA patent: A kind of hung basket used for glass-tempering oven
TENA <Certificate of High & New Tech Enterprise> granted by the government
