Help CenterDGY40G HYDRAUKIC PIPELAYER
Related Products
Specifications
Joystick Control , Max. lifting Capacity:40,000kg,UMMINS NT855-C280 Engine, Operating Weight:33,000kg
Main specification:
Lifting capacity at tipping point |
40000kg |
|||
Max. lifting moment at min .load overhang |
478KN.m(392KN*1.22m) |
|||
Max. lifting moment at max .load overhang |
404KN.m(73.5KN*5.50m) |
|||
Boom length |
7.0m |
8.0m |
||
Max. lifting height of the hook |
5.3.0m |
6.0m |
||
Hoisting speed(six part line) |
7m/min |
|||
Boom elevating time |
35s |
|||
Model of chassis |
DGY-40 |
|||
Model of diesel engine |
CUMMINS NT855-C280 |
|||
Rated power |
169kw/227HP |
|||
Model of oil hydraulic pump |
CBY4140/2010 |
|||
Rated working pressure of system |
20000kPa/2900psi |
|||
Lifting winch |
Hydraulic driven , Planetary transmission, Free-fall function |
|||
Diameter of lifting wire rope |
@20mm |
|||
Length of lifting wire rope |
60m |
|||
Ranging winch |
Hydraulic driven , Planetary transmission |
|||
Diameter of ranging wire rope |
@18mm |
|||
Length of ranging wire rope |
55m |
|||
Temperature of surroundings |
-20°C- +40°C |
|||
Overall dimension (L*W*H) |
With boom |
4.84*4.54*7.70m |
4.84*4.54*8.70 |
|
Without boom |
4.84*3.24*3.30 |
4.84*3.24*3.30 |
||
Ground pressure |
Without load |
82kPa |
83kPa |
|
Operating weight |
33000kg |
33150kg |
||
Joystick Control , Max. lifting Capacity:40,000kg 88,185 Ib, CUMMINS NT855-C280 Engine, Operating Weight:33,000kg 72,752 Ib
Feature:
Adopt special designed chassis for Pipelayer, two optional track shoe width.
Turbo CUMMINS engine, which reserves enough power to meet any tough working condition.
Adopt load sensitive hydraulic system, wrist control type single lever(Joystick)for easy operation and realize the compound movement.
Well-equipped safety device such as automatic load moment limiter, hoisting height limit switch, boom buffer limiter device, make operation more safe.
Modular design has facilitated removal /installation of components and shorten machine downtime.
Main components of hydraulic system adopt qualified international and brand en-hancing the reliability of the product.
Customized integrated solution for different working environment such as the frigid zone , the tropics ,deserts and marsh area.
