TS65HP FOUR WHEEL TRACTOR

TS65HP FOUR WHEEL TRACTOR thumbnail-1
TS65HP FOUR WHEEL TRACTOR photo-1
Negotiable MOQ: 4 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
Other, 2WD 4WD
Contact Supplier Request Quote Chat Now
Jiangsu Lionkin Industrial Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel Other, 2WD 4WD
Usage Farm Tractor
Drive Type Gear Drive
Power(W) 47.8KW
Certificate Other, EC ISO EPA
Brand Name LIONKIN-WZ
Model Number TS650 TS654
Place of Origin Shandong, China

Specifications

TS65HP FOUR WHEEL TRACTOR IS WITH GPS



 TS65HP FOUR WHEEL TRACTOR

Model TS650 TS654
General Specifications Type 4X2 4X4
Overall dimensions LxWxH(mm) 3830X1710X2200 3850X1710X2200
Constructional weight(kg) 1875 2030
Rated traction force(kN) 9.7 13.5
Wheel base(mm) 2040 2060
Front wheel tread(mm) 1270-1670(Adjustable) 1430-1630(Adjustable)
Rear wheel tread(mm) 1220-1620(Adjustable) 1220-1620(Adjustable)
Min.land clearance(mm) 420 370
Min.quality in use(kg) 2035 2337
Front wheel tyre size 6.0-16 8.3-20
Rear wheel tyre size 13.6-28 13.6-28
Min.turning radius(mm)(Unilateral Nonbraking/Unilateral Braking) 4100/3400 4200/3500
Theoretical speed(km/h) Creeper Shuttle gear Creeper Shuttle gear
1 0.47 2.73 0.47 2.73
2 0.74 4.29 0.74 4.29
3 1.14 6.7 1.14 6.7
4 1.77 10.32 1.77 10.32
5   8.22   8.22
6   12.95   12.95
7   20.18   20.18
8   31.05   31.05
Reverse 1 0.62   0.62
Reverse 2 0.99   0.99
Reverse 3 1.55   1.55
Reverse 4 2.37   2.37
Engine Model YTR4105T92
Type Inline,Vertical,Water-cooling,Four-stroke
12 hours power(kw) 47.8(65HP)
Rated Speed(r/min) 2300
Fuel consumption(g/kw.h) ≤240
Max.torque(N.m) ≥230
Speed of Max.torque(r/min) ≤1600
BorexStroke(mm) Φ105×120
Diesel Consumption(g/kW.h) ≤2.04
Starting mode Electric start
Break System Service Brake Mechanical,Wet,Disc
Parking Brake Locking footplate type
Transmission Clutch Dry,Single Piece,Double Acting,Constant Combining
Gear box 8 Forward gear,4 Reverse gear,Straight mesh sleeve shift,Additional equipment creeper, shuttle structure
Steering Hydraulic steering
Steering type Front wheel steering
Main Drive Spiral bevel gear
Differential Mechanism Pin-type,Two planet bevel gear,Closed
Final Drive Single stage,External,Planetary gear

Operating System Lifter tilling depth control Draft & position adjustable
Max.lifting capacity(kn) ≥10.8
Suspension type Postposition,Three-point,I category
Speed of P.T.O.(r/min) (540,1000),or (750,1000),or (540,750)
Type of P.T.O. Six splines,Postposition,Semi-independent
Traction  Equipment Swing rod
Optional Disposition Front ballast,Rear ballast,Shuttle gear,Air brake,Sealed luxury cabin and No hydraulic output
Units in one 40HQ 4 4
