Home > Packaging & Printing > Packing Machinery > Multi-Function Packing Machine > Fully Automatic Screw Packing Machine

Fully Automatic Screw Packing Machine

Name: Fully Automatic Screw Packing Machine
Brand: CHLBAO
SKU: 110786027
Availability: InStock

Fully Automatic Screw Packing Machine thumbnail-1

Fully Automatic Screw Packing Machine photo-1

US$ 3,900 - 8,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Application:

Food

Packaging Type:

Bags

Contact Supplier Request Quote Chat Now

Foshan Chuanglibao Packaging Machine Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou/Shenzhen/Foshan

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Application Food

Packaging Type Bags

Packaging Material Plastic

Automatic Grade Automatic

Driven Type Electric

Voltage 220V

Power 2KW

Place of Origin Guangdong, China

Brand Name CHLBAO

Model Number CB-3220

Weight 250KG

Dimension(L*W*H) L 1350* W 580 * H 1700 mm

Certification CE SGS BV

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Screw Packaging Machine
1. packing machine for hardware
2. filling machine with high speed
3. High degree
4,low price

Technical Specifications:

Model	CB-3220
Bag size	L (50-200) ×W (40-150) mm
Packing speed	30-100 bags/min
Measuring range	25-500 ml(10-150g)
Max width of film roll	320 mm
Power requirement	220 V, 50 HZ, 2 KW
Machine size	L 1350* W 580 * H 1700 mm
Machine weight	250 KG
Sealing type	Pillow sealing

Scope of application:

Suitable for many kinds of measuring equipments,and package different kinds of products ; such as puffy food, shrimp roll, peanut, popcorn, cornmeal, seed and sugar etc.

which shape is roll, slice and granule.

bags style:

Function Description:

The machine is controlled by double SCM (single chip) system and a large LCD (115*64 mm) in English display.
The clear manmachine interface is easy to understand. All operation by press keys for: temperature setting, length setting, counting setting, photo control, heating, mixing, move, run, stop.
Special and particular intelligence protection take the machine to auto stop to get the protection and display the fail information when the machine fail in temperature control, color mark hunt control and film finish.
Four intelligent temperature controllers. When the heating part or testing part fail to take the sealing temperature over 15 degree of the setting temperature, the machine will stop and display “heat over”. So you can make the wastage to the least.
The bag length is controlled by electronic photo switch. The bag length will be cut accurately. When the photo errs, the machine will stop and display “photo errs”.
When the packaging film is empty or broken, the machine will stop and display “film end”.
The intelligent counter: you can set the counter to a data you need, the machine will stop and take alarm when reach the data you set.
The working is stable, easy to use, high yield and low wastage.

Our vertical packing size

Model	CB-3220	CB-4230	CB-5240	CB-6848
Speed	Max 80bags /min	Max 60bags /min	Max 50bags /min
	Width:50-500ml	Width 150-1200 ml	width:50-300ml	Width:80-350ml
Bag size	L (50-200) ×W (40-150) mm	L (80-300) ×W (50-200) mm	L (80-400) × W (80-250) mm	(100-480) × (180-320)mm ( L × W )
Width of film	320mm	420mm	520mm	680mm
Rang	Max500ml	Max 1300ml	Max 3000ml	Max 6000ml
Power	220v 2kw	220v 2.2kw 50-60HZ	220v 4kw 50-60HZ	220v 5kw 50-60HZ
Film	POPP/CPP,POPP/PE,BOPP/PE,PET/AL/PE,NY/PE
Gas need	0.6Mpa 0.25m3/min	0.65Mpa 0.3m3/min	0.65Mpa 0.4m3/min	0.65Mpa 0.4m3/min
Size	L 900 * W 680 * H 1960 mm	L 1320 * W 950 * H 1360 mm	L 1150 * W 1795 * H 11650 mm	L1780mmW1350mmH1950mm
Weight	180KG	540KG	600KG	900KG
