walking behind tractor

Name: walking behind tractor
Brand: FENGLI
Availability: InStock

FOB Price

USD $400 - $1,900 / Set

20 Sets(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Walking Tractor
By wheel	2WD	Usage	Farm Tractor
Drive Type	Gear Drive	Power(W)	8000
Brand Name	FENGLI	Model Number	FL121
Place of Origin	China	After-sales Service Provided	Engineers available to service machinery overseas

1. easy operation and maintenance.
2. comapct structure, fantastic pass.
3.diesel engine.
4.gearbox.

Overall Dimension (mm)						2120×840×1160
Ground Clearance (mm)						210
Wheelbase(mm)						680~740
Weight (kg)						260
Semi-axis (cm)						340
Weight in use(with oil , water, tools) (kg)						350
Tyre Model						6.00~12
Tyre Pressure			Field Work			100~120(1.0~1.2kgf/c)
			Transportation Work			180~200(1.8~2.0kgf/c)
Power Connection						1040 Two B1830 V Belts
Engine						R190H/7.7kw/10.5hp/2300rpm
Gear	1	2		3	4		5	6	Reverse1	Reverse2
Speed(km/h)	1.68	2.61		4.22	6.79		10.57	17.08	1.29	5.22
Traction(N)	1800	1800		1800	1800		1800	1800	_	_

Engine	Pattern	Vertical, One Cylinder, Four Stroke, Diesel powered, Water-cooled
	Model	180,190,1100
	Displacement(L)	0.913
	Oil Consumption (g/ km. h)	320
	Engine Oil Consumption (g/ km. h)	2.72
	Rated Power(kw)	10.3
	Rated Speed(rpm)	2000
Machine Parameters	Type	Pull and Drive
	Overall Size(mm)	26809601250(without seat)
	Wheel Tread(mm)	800
	Minimum Ground Clearance(mm)	185
	Minimum Turning Radius(m)	0.9
	Structural Weight(kg)	360 (with connecting frame), 480(with rotary tiller)
	Tyre	6.00-12
	Theoretical Speed(km/h)	Forward:1.4,2.5,4.1,5.3,9.4,15.3 Reverse:1.0,3.8
	Rated Traction(N)	2400
	Gearbox	(3+1)×2
	Cooling Type	Evaporation
	Rear-Wheel Diameter(mm)	340
