chinese walking tractor for sale 12HP
- 20000 Set / Sets per Month
- QINGDAO
You May Like
Product Details
| Condition | New | Type | Walking Tractor | |
| By wheel | 2WD | Usage | Farm Tractor | |
| Drive Type | Gear Drive | Power(W) | 8530 | |
| Brand Name | ISO9001 | Model Number | FL121 | |
| Place of Origin | Shandong, China | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
FL121 walking tractorpull and drive.
the diesel: 195,but optional
compact construction
cultivate and transport.
Machine model:FL121
Type: pull and drive.
Overall dimensions(L×W×H): 2100×900×1250mm
Wheel tread: 680~740mm(stepless shift,adjustable)
minimum ground clearance: 210mm
minimum turning radius: 210mm
structure weight:270kg
Minimum working weight: 320kg(with fuel, water, revelant equippments and tools)
Transmission gear box: equipped with main transmissions and sub transmissions,6 forward gears and 2 reverse, full power sliding gear transmission,consists of (3+1) ×2 cylindrical wheel gear
gears:
forward | 1 | speed(km/h) | 1.98 | rated traction(N) | 1600 |
2 | speed(km/h) | 3.08 | rated traction(N) | 1600 | |
3 | speed(km/h) | 4.98 | rated traction(N) | 1600 | |
4 | speed(km/h) | 8.04 | rated traction(N) | 1600 | |
5 | speed(km/h) | 12.49 | rated traction(N) | 1616 | |
6 | speed(km/h) | 20.2 | rated traction(N) | 956 | |
reverse | 1 | speed(km/h) | 1.53 | rated traction(N) | / |
2 | speed(km/h) | 6.18 | rated traction(N) | / |
rated power: 8.53KW
rated rotating speed: 2400r/min
Connection of engine and transmission system: 2 triangle belt
Starting mode: rotating the hand crank or electric starting
2.engine model: 196
type/style: horizontal, single cylinder, four stroke and water cooled
type of cooling system: evaporative cooling or water-cooled, optional
3.capacity of fuel tank: 9L
4.drive wheel tyre: 6.00-12
5.tire pressure of drive wheel: 80~120KPa(0.8 ~1.2kgf/cm2 ) when farming
140 ~ 200KPa(1.4.8 ~ 2.0kgf/cm 2 ) when transporting
