Specifications
1. Automatic screen printing.2. Automatic flame treatment.
3. Automatic UV curing.
4. Soft Tubes Printing Machine.
Model JN-112UV 1 Single Colour Automatic Soft Plastic Tubes Printing Machine
The Single Colour Automatic Screen Printing Machine JN-112UV is specially designed for cosmetics, pharmaceutical industry, printing on the round surface of soft tubes within various patterns, like toothpaste tube and tube, penholder, lipstick tubes, bottle caps, cream bottle, cosmetics pipe, etc. It includes program controller, touch screen control system optical servo system, feeding machine, flame treatment machine, fast/slow synchronization transfer system. "No bottle no printing ", sensor fixation system. Easy operation make it a best general printing system solution to reduce the manual labor and hence improve the production efficiency. Reliability and speed make the JN-112UV ideal for off-line or in-line production.
Specification:
| Item | Specification |
| Max printing speed | 4000 pcs/hour |
| Printing area | 236mm x 170mm (Φ 75mm) |
| Size of printing object | 10mm < diameter < Φ 75mm 20mm < height < 200mm |
| Power supply | 380V 50 MHz |
| Main machine size | 1500mm x 1180 mm x 1900 mm |
| Machine cover area | 2600mm x 3600mm x 2000mm |
| Machine weigh | 1000 Kg |
| Power consumption | 4.5 KW |
Features:
1. The machine is specialized design for print on soft tubes, bottle caps, containers.
2. Feeding machine can load product to the screen printing machine automatically...Fully automatic feeding, flame treatment, UV screen printing and UV curing.
3. It is mechanical conveyer, touch control panel operation, easy to operation the machine. Fast adjustment, easy operation. Fast printing speed: 4000PC/hr
4. Fully automatic, the machine will alarm without product loading and no printing without product. So it can save much energy.
5. Wiht optical servo system, that can print more color and make the color register more precision.
6. All components and control system are from Germany and Japan, guarantee the quality of printing.
7. It is suitful for: Cosmetics, pharmaceutical industry, printing a variety of circular patterns on the surface, such as toothpaste tubes, tube, pen, lipstick tube, caps, cream bottles, cosmetic tubes, etc.
