High quality toilet paper making machine pulp machine drum pulper
This Drum type hydrapulper is mainly used in the paper making industry to breaking continuously and coarse screening of the waste paper material under the high consistency. It can maximum keep the physical property of the fiber.
Application & Features
1. Mainly used for continuous gentle pulping and coarse screening of waste paper under high consistency. Drum pulper can continuous pulp and preliminary screen, simple process.
2. It can gently pulp under 14%-18% high consistency to uttermost maintain the physical property of fiber.
3. Low damage to impurities and high efficiency of deslagging, which reduce the following equipment burden.
4. Low energy consumption, reduce running cost, improve the competitiveness for per ton pulp.
5. Long pulping residence time, sufficient fiber relief, low rate fine fiber loss.
6. Few quick-wear parts, continuous pulping, low maintenance cost.
Main Specification
| Type | ZG2500 | ZG2750 | ZG3000 | ZG3250 |
| Drum Diameter (mm) | Φ2500 | Φ2750 | Φ3000 | Φ3250 |
| Processing Capacity(t/d) | 70-120 | 140-200 | 200-300 | 240-400 |
| Work capacity(%) | 14-18 | |||
| Motor power(Kw) | 132-160 | 160-200 | 280-315 | 315-400 |
| Type | ZG3500 | ZG3750 | ZG4000 | ZG4250 |
| Drum Diameter (mm) | Φ3500 | Φ3750 | Φ4000 | Φ4250 |
| Processing Capacity(t/d) | 400-600 | 550-800 | 750-1000 | 1000-1400 |
| Work capacity(%) | 14-18 | |||
| Motor power(Kw) | 560-630 | 630-800 | 800-1000 | 1000-1400 |
Work Principle
Drum pulper set pulping and coarse screening with a body and used for continuous pulping all kinds of waste paper( newspaper, industrial board paper, mixed waste paper, etc.), and coarse screening the paper pulp after pulping, it is a reject treatment equipment. Drum pulper comprises three areas: pre-soaking area, high consistency pulping area and screening area. Firstly, waste paper is conveyed into pre-soaking area. After soaking, the waste paper enter into the high consistency pulping area for pulping under the consistency of 14% to 20%. With the rotation of the drum, the waste paper is took up by the lifting board on the inner wall, fall after rise to a certain height, and impact with the hard inner surface, so the waste paper in pulping area after repeated falls and strikes, under the mild pulping action of shear force and friction, was dissociated into single fiber, and the thin film, plastic, cloth and other impurities in the waste paper are not broken. Waste paper pulp after breaking will go along the dip Angle under the drum drive, from pulping area into the screening area; on the above of screening area equipped with a flush water pipe, the pulp will washed and diluted once entered the screening area. The pulp consistency will down to 3-4%. Now, the acceptable fiber through screen holes into the pulp chest, rough impurity is blocked by screen plate , stay in screening area and constantly elutriated, finally discharge from discharge mouth at the end of drum .
---About Leizhan
Zhengzhou Leizhan Technology Paper Machinery Co.,LTD is a professional manufacturer with more than 30 years manufacturing experience in making complete set of screening, impurity removal, pulping and refining equipment.
Our company is located in Zhengzhou which is the hometown of machinery in Henan Province. We have more than 200 staffs including 50 engineering technicians which can be your best technical support.
---Trading Nation
We have exported to many foreign countries,for example, Russia, Egypt, Iran, Argentina, Uzbekistan, Turkmenistan, Burma, Vietnam, Pakistan etc. And we are looking forward to establish cooperation relationship with friends all around the world.We warmly welcome you on-the-spot investigation!
Leizhan focuses on research and development of advanced technology and customer-oriented products as well as building up core competitiveness to makes paper pulp machinery a pioneer of the industry.
We have many patents of pulping equipment,like impurity separator, high and low density cleaner,grapple,pressure screen and so on.
Acceptance standard
- Unless stipulated in the technical documents accordingly, technology acceptance standards of designed main parts are in accordance with relevant state departments issued current relevant standards.
- providing main parts technology acceptance standard of technical design.
Technical service
- During paper machine installation, We cooperate with buyer for technological improvement to reach desired results.
- We explains paper machine performance, structure and operation to buyer related people for free.
Quality guaranteed
- We makes sure paper machine achieve promised performance with correct installation, commissioning, normal operation and maintenance.
- In warranty period, for quality problem, we repair and replace defective parts for free(except quick-wear part).
Welcome to visit us, we are located in Zhengzhou city, Henan province, We will pick you up at air port.
