Dake DT-66B Machine Manufacturer
- shanghai port
You May Like
Product Details
| Use | Food | Material | Plastic | |
| Plastic Type | PP | Type | Cup | |
| Place of Origin | Shanghai, China | Brand Name | Dake machinery | |
| Model Number | Dake -DT66B |
Product Description
Specifications
1,reasonable price2,good quality
3,consummate after-sale service
1,Thermoforming machine
Plastic Thermoforming Machine is a kind of efficient automatic plastic thermoforming technical process.It can
finishproducing at one time through feeding,heating ,streching,forming and sidecutting,etc.It can produce such as
PP,PE ,PS,and ABS,etc. This machine has wide used ,This machine is mainly used for producing disposable
plastic vessels, such as teacup,milkcup,instant noodles bowl and other plastic products,etc..
2, Main technical parameters of equipment
Model | DT66B |
Sheet width | 300-600mm |
Sheet thickness | 0.3-1.5mm |
Max diameter of sheet rolll | 700mm |
Max forming area | 620*220mm |
Max forming depth | 120mm |
Revolution | 20-35mould/min |
Powrr | 83KW |
Voltage | Three phase 380V/50Hz |
Air consumption | 0.7Mpa*1.6m3/min |
Dimension | 9.5m*1.5m*2.7m |
Weight | 5T |
