Dake DT-66B plastic cup making machine

Specifications

1,reasonable price
2,good quality
3,consummate after-sale service

1,Thermoforming machine

Plastic Thermoforming Machine is a kind of efficient automatic plastic thermoforming technical process.It can

finishproducing at one time through feeding,heating ,streching,forming and sidecutting,etc.It can produce such as

PP,PE ,PS,and ABS,etc. This machine has wide used ,This machine is mainly used for producing disposable

plastic vessels, such as teacup,milkcup,instant noodles bowl and other plastic products,etc..

2, Main technical parameters of equipment:

Model	DT66B
Sheet width	300-600mm
Sheet thickness	0.3-1.5mm
Max diameter of sheet rolll	700mm
Max forming area	620*220mm
Max forming depth	120mm
Revolution	20-35mould/min
Powrr	83KW
Voltage	Three phase 380V/50Hz
Air consumption	0.7Mpa*1.6m3/min
Dimension	9.5m*1.5m*2.7m
Weight	5T
