Corrugated Cardboard Production Line Duplex Paper Board Calendering Machine
- Shanghai Qingdao
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Wholesale Paper Mill Used Press Felt With Factory Price
-
Paper Mill Machinery Part Pneumatic Scraper for Paper Making
-
Flotation Waste Paper Deinking Machine
-
Waste Apper Ink Removal Equipment in a4 Paper Production Line
-
Complete Paper Mill Deinking Machine for Paper Recycling
-
Small Investment Waste Paper Recycling Processing Machine Steam Boiler
Product Details
| Place of Origin | Henan, China | Brand Name | Leizhan | |
| Model Number | paper machine paper calender |
Paper industry calendering machine for duplex paper board in Wooden case or as customers' requests.
Product Description
Corrugated cardboard production line duplex paper board calendering machine
Corrugated cardboard production line duplex paper board calendering machine consists of roller, rack, backplane, adjustment device, transmission system, roller temperature control device, security device,lubricating device.
The roller is made of Chilled Cast Iron alloys,whose work surface has high hardness, wear-resistance and durable life.Steem,cooling water and heat-conducting oil can pass into the roller's cavity,so that the working temperature can be adjusted in order to meet the technological requirements.
What's more,roll spacing can be adjusted both by manual or electric mode.
In addition,roller bearings' lubricating can adopt drier oil or dilute oil.
It can be used for rubberizing and frictioning of textile material,rubberizing of wirecord
fabric, sheet and counter plate(embossed) of rubber material, separation of fabric and film, as well as joint of multi-layer laminate film.
Technical Data
Type | XY-4F230 | XY-4F250 | XY-4F300 | XY-4F360 |
Roller working part length(mm) | 635~720 | 635~720 | 600~900 | 900~1200 |
Width of rolled products(mm) | ≤500~600 | ≤500~600 | ≤500~700 | ≤700~1000 |
Min.thickness for calendering(mm) | ≥0.20 | ≥0.20 | ≥0.20 | ≥0.20 |
Designed roller speed(m/min) | 1.04~10.35 | 13.60 | 16.49 | 22.16 |
Motor power(kw) | 22 | 22 | 37 | 55 |
Overall dimendion(L*W*H)(mm) | 2650/2750×1200×1800 | 3500/3600×1250×1900 | 4000/4300×1400×2300 | 4400/4700×1700×2400 |
Weight(t) | ~3.5 | ~3.5 | ~8 | ~13 |
Type | XY-4F400 | XY-4F450 | XY-4F560 | XY-4F610 |
Roller working part length(mm) | 1200~1400 | 1200~1500 | 1530~1650 | 1730 |
Width of rolled products(mm) | ≤1000~1200 | ≤1000~1300 | ≤1300~1400 | ≤1500 |
Min.thickness for calendering(mm) | ≥0.20 | ≥0.20 | ≥0.20 | ≥0.20 |
Designed roller speed(m/min) | 22.20 | 24.98 | 31.09 | 30.10 |
Motor power(kw) | 75 | 110 | 160 | 200 |
Overall dimendion(L*W*H)(mm) | 5300/5500×1860×2510 | 6150/6450×2300×3300 | 6900/7000×2600×3860 | 7500×3700×4000 |
Weight(t) | ~16 | ~30 | ~50 | ~58 |
1.Pre-sales Service
- Offering comprehensive technical and business consultation services;
- Proposing the most suitable scheme and equipment for our clients;
- Designing and fabricating targeted products according to the special requirements of clients;
- Training periodically high qualified service technician.
2.After-sales Service
- Highly inspecting equipments in every working procedure, quality comes first;
- Fast & Safe Delivery;
- Assisting our clients for foundation construction of equipments;
- Dispatching engineers to install and debug equipments;
- Training the first-line operators on site;
- Regularly visit clients to solve production problems;
- Providing life-long maintenance service;
- Providing technical exchanging;
Zhengzhou Leizhan Technology Paper Machinery Co.,LTD is a professional manufacturer with more than 30 years manufacturing experience in making complete set of screening, impurity removal, pulping and refining equipment. Our company is located in Zhengzhou which is the hometown of machinery in Henan Province. We have more than 200 staffs including 50 engineering technicians which can be your best technical support. With high quality products and perfect pre-sale and after-sale service, we have won lots customers from all over the world.
