Specifications
disposable plastic thermoforming machine plastic cup, lid, bowl making machine, PP, PE, PET, HIPS, PVC, biodegradable materialplastic cup thermoforming machine
Usage:
This machine is mainly used to form PP/PS/HIPS/PET/PVC sheet into various kinds of disposable
cups, such as water/juice drinking cup, yoghurt cup, ice-cream cup, jelly cup, etc. It also could be
used for making some regular shape containers, such as plate, dish, bowl, covers, etc.
You could make different products with different moulds.
How To Custom My Own Thermoforming Machine?
Code |
Step |
Description |
1 |
Enquiry |
Discuss on drawing or the samples to make clear customer’s requirements and the best solutions. |
2 |
Quotation |
The best price will be worked out according to customer’s requirement |
3 |
Order |
Place order and confirm the deposit. |
4 |
Design |
Machine design for customer’s approval |
5 |
Tooling* |
Only after design approval, can machine making be started. |
6 |
Report |
Processes reported will be sent aperiodically. |
7 |
Sample |
5-20pcs ( depends on products) qualified samples will be sent to customer for approval |
8 |
Approval |
Sample approval or modify the machine until sample approved. |
9 |
Delivery** |
Pack the thermoforming machine for shipment. |
*Prototype available before tooling, if needed.
**The machine can be kept in factory for future injection production which only follow your order.
Technical Parameter:
Forming Area |
510mm *570mm |
Depth of Draw |
125mm or 100mm |
Suitable material |
BOPS PP PS PVC PET PVC |
Speed (Dry run) |
20-35cycles/min |
Material Thickness Range |
0.3mm - 1.5 mm |
Sheet Width |
600mm maximum |
Material Roll Diameter |
700mm (28") Max. |
Power Supply |
3-N AC380V±15V ,50Hz |
Power Consumption |
83kw |
Air Pressure |
0.7Mpa |
Air Consumption |
0.7Mpa*1.6m³/min(Approximate) |
Machine Dimensions |
9.5m*1.5m*2.7m |
Machine Weight |
5000kg |
Certificate |
ISO9001 |
fast food box
