Automatic 6 color plastic bucket printer DAKE-350T

Specifications

Automatic 6 color plastic bucket printer DAKE-350T
1.reasonable and competitive price
2.certificate:ISO9001:2000

Automatic 6 color plastic bucket printer DAKE-350T



Brief introduction:



1. With more than 10 years' experience, we have achieved good reputation and reliability both at home and abroad.



 2. Our main products:



 a. plastic cup coiling machine



 b. The bent offset printer



 c. Thermoforming machine



 d. Thermoforming mold



 e. Extrusion line



 What we sell is not the best, but the most fitting.





Quick Details

Type: Offset Printer	Condition: New	Plate Type: Letterpress
Place of Origin: Shanghai, China (Mainland)	Usage: Barrel Printer	Model Number: DAKE--350T
Color & Page: Multicolor	Gross Power: 25kw	Max printing square: dia350*300mm
Colors: 6	Air consumption: 0.5m³/min	Automatic Grade: Automatic
Height: 50-220mm	Taper degree of barrel: 2°-10°	Dimensions(L*W*H): 5m*4m*3m
Diameter of rim: dia125-400mm	Fastest printing:   125mm- 200mm 135pcs/min 200mm- 400mm  45pcs/min	Weight: 8000kg



Packaging & Delivery

Packaging Details:	according to the exported demand
Delivery Detail:	30 days



Specifications



 Automatic 6 color plastic bucket printer DAKE-350T



 1. Use

Model DAKE-350T

Automatic Plastic Bucket Printer is used for printing plastic bucket which is six colors.



2. Characteristic

a. Very quick change over of mandrels

 b. Automatic equip UV on-mandrel curing system

c. Controlled by frequency conveniently and quickly

d. Checking accurately, conveniently and quickly

e. Control and error check

f. Layer printing effects

g. Corona before printing

h. Color station opening structure



 3. Main technical parameters of the equipment

Model Number: Dake-350T

Total power:25KW
Air consumption:0.5m³/min
Diameter of barrel rim: 125mm- 400mm
Max Height of barrel:400mm
Taper degree of barrel: 2°-10°
Max printing square: 350*300mm
Fastest printing:  125mm- 200mm 135pcs/min
200mm- 400mm45pcs/min
Drying method: UV
Size of machine: 5m*4m*3m
Total weight:8000kg





4. Picture of the machine





5.  Pictures of the barrels
