Bizsoft Datacard CD800 dual sided plastic membership smart card printer

Bizsoft Datacard CD800 dual sided plastic membership smart card priner

Print technology

Direct-to-card dye-sublimation/resin thermal transfer

Print capabilities

One-sided (simplex) or optional two-sided (duplex) edge-to-edge printing

Full-color and monochrome printing capability in the same printer

Alphanumeric text, logos and digitized signatures; 1D/2D bar code images

Printer pooling/sharing (available soon)

Print resolution

Standard mode: 300 x 300 dots per inch; standard text, bar code and graphics printing

High-quality mode: 300 x 600 dots per inch for enhanced text, bar code and graphics printing; 300 x 1200 dots per inch for enhanced text and bar code printing

256 shades per color panel

Print speed

Full-color: Up to 220 cards per hour, one-sided (YMCKT); up to 165 cards per hour, two-sided (YMCKT-K)

Monochrome: Up to 1,000 cards per hour, one-sided (Black HQ)

Card capacity

Automatic feed: 100-card input for 0.030 in. (0.76 mm) cards; 25-card output standard

Front exception card slot

Separate reject location and holding tray (two-sided printer model only)

Input hopper empty detection

Physical dimensions

One-sided printing: L 17.4 in. x W 8.8 in. x H 8.8 in. (44.2 cm x 22.4 cm x 22.4 cm)

Two-sided printing: L 21.2 in. x W 8.8 in. x H 8.8 in. (53.8 cm x 22.4 cm x 22.4 cm)

Six-compartment multi-hopper: L 27.5 in x W 16.5 in. x H 14.5 in. (69.9 cm x 41.9 cm x 36.8 cm)

Weight

One-sided printing: 9.0 lbs (4.1 kg) (depending on options)

Two-sided printing: 12.0 lbs (5.4 kg) (depending on options)

Six-compartment multi-hopper: 33.0 lbs (15.0 kg)

Operating system support for printer driver

Windows® 7 / Windows 8 (32 and 64 bit)

Windows XP SP3 / Windows Server® 2003 R2 (32 bit)

Windows Server 2012/2008 (64 bit)

Microsoft Windows® Hardware Quality Labs (WHQL) certified

Environment/energy-saving features

Biodegradable supply cores made with EcoPure® additive

Recyclable enclosure plastics (marked with recycle symbol per Resin Identification Code)

Recyclable packaging

Included with printer

Printer driver CD, Quick Install Guide and warranty

IDCentre™ Intro identification software

Cleaning pen

Cleaning roller spindle

USB cable

Power supply

Power cord (region-specific)
