Specifications
Pellets type thermoplastic polyurethane for injectiontpu 80 tpu 95 need to be:
virgin high quality transparent material
Polyurethane hotmelt adhesive powder—TPU
A.Feature
Low temp,good elasticity, good bond strength,Excellent in resistance to washing and dry cleaning,no leaking,
environmentally friendly etc.
B.Application
Wildly used in heat transfer printing:swimsuit printing,hot stamping;flocking ink;printing ink;transfer printing etc;
High-grade interlining:woven and non-woven interlining;shoes lining;shoulder lining;cap lining etc;Filter materials;Automobile trims;Powder coating;
lamination etc.
C.Specification
Package:20kg/bag
Particle size:0-80um/80-170um/80-200um/120-200um/150-250um
Or according to the customers’ special requirements.
D.Technical data
Product |
U1101P |
U1106P |
U1108P |
U1036P |
U1075P |
Melting temp (°C) |
60-75 |
70-85 |
85-105 |
95-105 |
115-125 |
Melt Index (g/10min@160) |
40±2 |
40±2 |
30±2 |
15±2 |
15±2 |
Viscosity (Pa.s@160) |
280 |
300 |
350 |
320 |
300 |
Operating temp (°C) |
85-115 |
115-125 |
125-145 |
135-145 |
145-165 |
Operating time (S) |
10-20 |
10-20 |
10-20 |
10-20 |
10-20 |
Operating pressure (kg/cm2) |
0.5-1.5 |
0.5-1.5 |
0.5-1.5 |
0.5-1.5 |
0.5-1.5 |
Resistance to washing |
40°C |
40°C |
40°C |
40°C |
40°C |
Resistance to laundry |
Good |
Good |
Good |
Good |
Good |
E.Process suggestion
The product will be processed by scattering machine;coating machine;lamination machine;ink mixer;manual
powder etc.
F.Stores
To avoid UV,it is put on wooden pallets and kept in cool and dry places.
Remarks:The above information and technical support are based on our current knowledge and experience.Theyare without guarantee and
legal claim.To obtain the best processing conditions,we suggest customers test the samples before using our products.
G. Applications
1. TPU hotmelt adhesive powder for automotive trims
2. TPU hotmelt adhesive powder for fusible interlining
3. TPU hotmelt adhesive powder for swimsuit printing
H. Packaging and shipment
1. powders and granule
1). 20kgs/bag & 25kgs/bag, with composite kraft paper bag
2). palletizing, suitable for sea and air transportation
3). shrink film
2. films and webs
1). 1-2 rolls packed by composite kraft paper bag
2). palletizing, suitable for sea and air transportation
3). shrink film
