Freezing Load Test Package M Test Package

Iec62552 Iso15502 Freezing Load Test Package M Test Package

Appliance:

Now test package generally used in the test of refrigerators’ performance, it has advantage of security, price and durability

refrigerator  freezing M load test package

The freezing load test package is made according to GB/T8059.2 GB/T8059.4, and we can also make the package in different standard according to different requirement.

Test package is placed in the frozen food storage compartment and ice greenhouse performance test, or in a freezer to test the freezing capability test, to simulate the load capacity of frozen food.

1. The freezing point of the test package is -1℃ (Its thermal performance is equivalent to lean beef)

2. Packaging material is a thin layer of plastic, or with appropriate materials which can do medium vapor exchange with the environment, immediately seal the packaging material after filling,

3. When measured in ice greenhouse, must use the  -5℃ test package.

4. You cannot use in test of testing freezing capacity and load temperature rise time.

5. M package means the 500g test package, it equipped with a thermocouple in the geometric center to measure the temperature. The thermocouple contact the package directly.

1.  International and euro standard test package (ISO 15502/GB8059.1-4)

-1 ℃ and -5℃ two type

M package with thermocouple wire or embedded copper pipe,  -1℃ / -5℃

2.  Australia Standard test package AS1731.4-2003

M package with thermocouple,  according to GB8059.1

 (Quality is estimated by the density and volume size)

 3. Sawdust test package AHAMHRF-1 2007/ SASO 2664-2007

 mainly made of hard wood sawdust

M package  with thermocouple or embedded copper pipe

4. North America Commercial use test package  AS72-2005

M package  with thermocouple wire
