Tungsten Carbide wear resistant parts, Welded Wear Plates
- 1000 Kilogram / Kilograms per Month
- Guangzhou Port
-
API-7-1 Standard single cone drill bit
-
6 7 11 12 degree Diameter 32mm Taper Knock off drill bit
-
Oil Well Api Oilfield Fishing Tool Overshot Grapple Assembly/Oil Well Magnetic Fishing Head/Cable Righting Fishing Head
-
Drop Shipping API Oilfield Releasing Overshot 4 11/16" Oil Fishing Tools LT119
-
API compliant fishing tool overshot for oil field downhole work
-
Oil Well fishing tool sucker rod overshot/circulating overshots
Product Details
| Place of Origin: | Hunan, China | Brand Name: | Newmetal | Model Number: | Customized |
| Type: | Other, wear plate | Machine Type: | Crusher | Certification: | Other, ISO9001 |
| Material: | Other, Chromium, high chromium + white iron+mild steel plate | Processing Type: | Forging | Use: | Ore Mining |
Product Description
Newmetals Highly abrasion Tungsten Carbide Overlay Welded Wear Plates
Overlay Welded Wear Plates
It is chromium carbide overlay welded on a special mild steel backing plate. The overlay consists of mainly supper hard chromium carbide particles embedded in softer matrix
Advantages:
- Extending wear life
- Increased abrasion and impact resistance
- Minimise down-time and lower overall cost
- Extremely smooth surfaces
- Easy to cut, shape, weld and install
- Reduced maintenance and increase production
Applications:
- Chutes/Hoppers/Bins/Earthmoving Equipments
- Transfer Points/Truck Beds
- Rock Box Edges/Impact Walls/Screen Plates
| Chemical Composition | Macro-Hardness | Abrasion Resistance | mpact Resistance |
| C:4.0-5.0% Mn: 1.0-5% Cr: 30-40% Fe and others: balance. Actual chemistry will vary with overlay thickness. (Custom chemistries can be developed for specific applications.) | 55-62 HRc. The hardness is a composite of hard chromium carbides (1750 V) and tough austenitic matrix. The hardness can vary depending on the thickness of the overlay. | 30 to 1 over mild steel and 3-4 times over HARDOX 400. | Will withstand continuous moderate impact. Custom overlays can be formulated to withstand higher impact. |
Thickness | Size(mm) | Thickness | Size(mm) |
8(4+4) | 1200*2400 1500*3000 2200*300 |
18(10+8) | 1200*2400 1500*3000 2200*300 |
10(6+4) | 1200*2400 1500*3000 2200*300 |
17(8+9) | 1200*2400 1500*3000 2200*300 |
12(8+4) | 1200*2400 1500*3000 2200*3000 |
19(10+9) | 1200*2400 1500*3000 2200*300 |
13(8+5) | 1200*2400 1500*3000 2200*3000 |
20(10+10) | 1200*2400 1500*3000 2200*300 |
15(10+5) | 1200*2400 1500*3000 2200*3000 |
22(10+12) | 1200*2400 1500*3000 2200*300 |
12(6+6) | 1200*2400 1500*3000 2200*3000 |
24(12+12) | 1200*2400 1500*3000 2200*300 |
14(8+6) | 1200*2400 1500*3000 2200*3000 |
25(13+12) | 1200*2400 1500*3000 2200*300 |
16(8+8) | 1200*2400 1500*3000 2200*3000 |
25(10+15) | 1200*2400 1500*3000 2200*300 |
Product Showcase
Zhuzhou Newmetal Materials Co., Ltd is a refractory metal manufacturer specializing in the raw material and deep-processing product of tungsten, molybdenum, tantalum, niobium, rhenium and tungsten carbide.
• We have conquered the technological difficulties in welding between the tungsten carbide wear-resistant material and stainless steel-based and iron-based. The geometrical tolerance of weldment can be controlled in level A.
• Relying on powder metallurgy institute and engineering materials institute of Central South University, We have established a production-learning-research base to provide powerful technologic support for products R&D. And we have the whole production equipment from mixing to finish machining, including the world’s most advanced cold isostatic pressing machine which can manufacture the widest and longest plate.
•Our 21 technicians, 10 after-sales personnel and 120 manufacturing workers are all heartedly at your service.
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
