DMX512/1990 RGB 144W Outdoor LED Wall Washer

Specifications

DMX512 RGB LED Wall washer
1.RGB,DMX512,IP65 outdoor lighting
2.Voltage:85-265V/AC,50-60Hz
3.LED Qty:144*1W RGB
4.AL housing

DMX512/1990 RGB 144W Outdoor LED Wall Washer

 FEATURES

1.     LED Wall washer have High efficiency, energy saving

2.     Reliable and safe

3.     Long life span, over 50,000 hours

4.     Flexible in application, can be made into product of point features, line shape and polygon shape

5.     No radiation of UV and IR, recyclable, no pollution

6.     Easy to control, the light is dimmable by adjust electricity current

7.     Good heat dissipation, no start up delay, no stroboscopic light



LED WALL WASHER SCOPE OF APPLICATION

1.     LED Wall washerWall reflecting light on many occasions, such as KTV, pub, building, park and so on

2.     Indoor lighting in franchise house and shopping mall

3.     Decoration in the place of entertainment, bar, coffee house

4.     Lighting in museum, art gallery

5.     Stage lighting in commercial theatre, auditorium

6.     Lighting in hotel

7.     Lighting in meeting room and multi-function room

8.     Lighting in exhibition and fashion show

9.     Lighting in living room and home theatre



LED WALL WASHER Specifications

Light Source                          high brightness LED chip constant-current supply

LED Quantity                         144*1W high power LED

Lens Angle                             15, 25, 45, 90 degree

Light Color                             red, yellow, blue, green, white, warm white

Wave Length                          R=632nm, G=525nm, B=470nm

Luminous Flux Attenuation      ≤10% after 20000 hours

Illumination range                   12-20M

Water Proof                           IP65

Output Power                         144W

Power Supply                        100W 220VAC

Input Voltage                         220V,DC12V

Lighting Effect                       7-color jumpy changing, gradual changing, flash changing, 7-color constant lighting, DMX 256-level gray brightness adjusting, DMX programme (realize thousands of lighting effect when several wall washer connected)

Color Rendering Index            >75

Warranty Period                     2 years

Life Span                               >50000hrs

Light efficiency                      >80Lm/W

Lamp Cover                           smooth surface, no air bubble in glass cover, age-resistant and anti-corrosion

Electric Shock Protection        GB7000.1 standard

Operating Temperature           -25°C-+50°C
