tungsten copper alloy disc ring wheels copper tungsten electrode
Copper tungsten erosion wheels and copper tungsten erosion discs are also known as electrodes for erosion, or erosion electrodes. Thanks to very high melting point of tungsten, tungsten copper rotary electrodes have very long service life comparing to copper or graphite electrodes.
Advantage
1.High conductivity and routine maintenance can ensure the stability of the working tungsten copper rotary electrodes.
2.High thermal conductivity can help the PCD to endure the high temperature.
3.High density can ensure the least bend destroy of the PCD blades.
4.heat-resistant
5.ablate-resistant
6.high-intensity
7.excellent thermal andelectrical conductivity
8.easy to be machined
Application
1.Switch contacts, high voltage circuit breakers, medium voltage circuit breakers, air & oil immersed (SF6 circuit breakers)
2.Tungsten copper arcing tips or copper tungsten arc runners
3.Make & break contacts
4.Heavy duty conductors, relays & switches.
5.Circular saw blades with PCD cutting edges are machined by using the erosion technique. We employs the advantages of tungsten copper rotary electrodes with high erosion rates and a guaranteed optimal surface finish at the PCD cutting edge.
The copper tungsten rotary electrode is positioned so that erosion is performed with the face of the cup wheel. The face of the electrode is used to achieve precise accuracy at the cutting edge with clearly defined angles – a major advantage for the cutting performance of the saw blade.
We have been supplying tungsten copper rotary electrodes for customers like Vollmer(Germany), Walter(Germany), Lach(Germany), Enokida(Japan) and other EDM machines.
We are able to offer cup electrodes, electrode wheels or any other WCu erosion discs according to your requirements.
| Type | Chemical composition (wt%) | Density | Hardness | Resistivity | IACS | Bending strength | ||
| Cu | Total impurity content(≤) | W | g/cm3 (≥) | HB Kgf/mm2 ( ≥) | μΩ.cm (≤) | % (≥) | MPa (≥) | |
| W50/Cu50 | 50±2.0 | 0.5 | balance | 11.85 | 115 | 3.2 | 54 | -- |
| W55/Cu45 | 45±2.0 | 0.5 | balance | 12.3 | 125 | 3.5 | 49 | -- |
| W60/Cu40 | 40±2.0 | 0.5 | balance | 12.75 | 140 | 3.7 | 47 | -- |
| W65/Cu35 | 35±2.0 | 0.5 | balance | 13.3 | 155 | 3.9 | 44 | -- |
| W70/Cu30 | 30±2.0 | 0.5 | balance | 13.8 | 175 | 4.1 | 42 | 790 |
| W75/Cu25 | 25±2.0 | 0.5 | balance | 14.5 | 195 | 4.5 | 38 | 885 |
| W80/Cu20 | 20±2.0 | 0.5 | balance | 15.15 | 220 | 5 | 34 | 980 |
| W85/Cu15 | 15±2.0 | 0.5 | balance | 15.9 | 240 | 5.7 | 30 | 1080 |
| W90/Cu10 | 10±2.0 | 0.5 | balance | 16.75 | 260 | 6.5 | 27 | 1160 |
We can offer various type with different functions for customers, not only manufacture according to the international standard, but also can design as per the requirements of customers.
Please choose freely from the wide range of already available tungsten copper alloy disc ring wheels copper tungsten electrode or contact us with your specifications.
Product display
Zhuzhou Newmetal Materials Co., Ltd is a refractory metal manufacturer specializing in the raw material and deep-processing product of tungsten, molybdenum, tantalum, niobium, rhenium and tungsten carbide.
• We have conquered the technological difficulties in welding between the tungsten carbide wear-resistant material and stainless steel-based and iron-based. The geometrical tolerance of weldment can be controlled in level A.
• Relying on powder metallurgy institute and engineering materials institute of Central South University, We have established a production-learning-research base to provide powerful technologic support for products R&D. And we have the whole production equipment from mixing to finish machining, including the world’s most advanced cold isostatic pressing machine which can manufacture the widest and longest plate.
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
