Help CenterIEC60529 IPX Waterproof Tester IPX3/IPX4 Rain Oscillation Tube Tester
Related Products
-
IEC 60529 Oscillating Tube Tester of Water Test KitsNegotiableMOQ: 1 Set -
IEC60529 IP Waterproof Grade Test ChamberNegotiableMOQ: 1 Piece
-
Safety Vacuum Drying OvenNegotiableMOQ: 1 Set
-
ASTM Salt Spray Test ChamberNegotiableMOQ: 1 Set
-
IEC 60068-2-78 Constant Temperature and Humidity Test Chamber PriceNegotiableMOQ: 1 Set
IEC60529 IPX5 IPX6 Handheld Water Jest Nozzles Dia 6.3mm 12.5mm
Oscillating tube tester is designed and manufactured in accordance with the standard requirement of IEC60529 IPX3 and IPX4. It is used for the waterproof test of the electrical equipment. The oscillating tube part of this device is controlled by adjustable-speed motor and crank-link mechanism. This device is reciprocating swing from the place of ±60°to another one of ±175°with the speed required by the standard through machine adjusting angle. The angle adjustment is accurate. The structure is stable and durable. It is equipped with rotating stage through which the rotating of 90°can be achieved. It is also equipped with clean water filtration unit to prevent the pinhole from jamming.
Technical parameters:
No. |
Item |
parameters |
1 |
Power supply |
Single phase AC220V,50Hz |
2 |
Water supply |
Water flow rate>10L/min±5% clean water without inclusion. This device is equipped with clean water filtration unit |
3 |
The size of the oscillating tube |
R200 ,R400,R600,R800,R1000,R1200,R1400,R1600mm Optional,stainless steel |
4 |
Water hole |
0.4mm |
5 |
Included angle of two holes |
IPX3:120°; IPX4:180° |
6 |
pendulum angle |
IPX3:120°(±60°); IPX4:350°(±175°) |
7 |
Raining speed |
IPX3:4s/time(2×120°); IPX4:12s/time(2×350°); |
8 |
Water flow |
1-10L/min adjustable |
9 |
Testing time |
0.01S~99 hours 59mins,can be preset |
10 |
The diameter of rotary plate |
600mm |
11 |
Speed of rotary plate |
1r/min,90°place limited |
12 |
Load bearing of rotary plate |
≤150kg electrical equipment (without rotary column); stand column≤50kg |
13 |
Pressure gauge |
0~0.25MPa |
14 |
Site requirements |
Dedicated IP waterproof test room,The ground should be flat with illumination 10A waterproof leakage switch(or socket)used for equipment. With good function of inflow and drainage. Ground installation |
15 |
The area |
According to the oscillating tube chose |
