Waterproof System Ipx rain Spray Testing Chamber /water Spray Tester
Application
The rain test system is strictly designed according to IEC60529. It’s applied to the Electrical equipment of the waterproof test of IPX3 and IPX4.
Rain resistance testing machine is used to test the water/rain/moisture proof ability of products and materials such as lighting, auto parts, household appliances and other products under the condition of moisture or rain.Through this method, to see the influence of water on the products. Its design considered auto maker's and electronic industry testing. Large viewing glass window can let the operator see the specimen clearly.
Features
1 Test automotive parts, electrical parts' water resistance and water proof performance.
2 Digital setting, easy operation and maintenance.
3 Adopt large transparent window to observe testing samples conditons.
4. Inner chamber material is imported steel plates; Shell is made of #304 stainless steel.
5. Water pressure and flow rate can be adjustable.
6.Glass door with wiper
7.Pneumatic drive of swivel tube
8.Adjustable swivel angle
9.Replaceable swivel tubes
10.Nozzle fittings can be swivelled and replaced
Technology Parameter
Power Supply |
Single phase: AC220V, 50Hz |
Swing Pipe diameter |
19mm, thickness 2mm |
Swing Pipe radius |
R800 (304 stainless steel) |
Orifice diameter |
0.4mm |
Orifice angle |
IPX3: 120°; IP4X: 180° |
Pendulum Angle |
IPX3: 120°(±60°); IPX4: 360°(±180°) |
Swing Pipe Speed |
EPX3: 4s/time (2x120°) IP4X: 12s/time (2x180°) |
Water discharge |
1-10L/min, adjustable |
Test time |
0-999mins, can preset |
Swivel table diameter |
700mm |
Swivel table speed |
(1-5) rpm |
Tiltable Angle |
15° |
Swivel table rotation angle |
900°,continuous rotation |
Pressure Gage |
0~0.25MPa |
Welcome to your kindly enquiries!
