ISO & IEC Corrosion Resistance Salt Spray Tester
Usage:
This machine has a standardized test method to check corrosion resistence of coated samples. Salt spray test is an accelerated corrosion test that produces a corrosive attack to the coated samples in order to predict its suitability in use as a protective finish. The appearance of corrosion products (oxides) is evaluated after a period of time. Test duration depends on the corrosion resistance of the coating; the more corrosion resistant the coating is, the longer the period in testing without showing signs of corrosion. Different coatings have different behaviour in salt spray test and consequently, test duration will differ from one type of coating to another.
1.Technical parameters:
| Model | CX-60 | CX-90 | CX-120 |
|
Inner Box Size (W*D*H) mm |
600*450*400 | 900*600*500 | 1200*800*500 |
| Outsider Box Size(W*D*H) mm | 1070*580*1030 | 1380*800*1150 | 1700*950*1210 |
| Testing capacity | 108L | 270L | 480L |
| Power | 220V,1.5KW ,50HZ | 220V,1.5KW ,50HZ | 220V,3KW,50HZ |
2. Technical Features:
Box material : Local temperature and humidity inside and outside the box are used for A-level gray high-corrosive PVC, for salt spray, copper acetate, and other test specifications Test
- Saturation pressure barrel : It uses the A-level German imports of gray PVC material.
- Laboratory Racks: It uses sophisticated Class A gray PVC material designed "V" shape long, products tested by the 15 ° -30 ° angle be adjusted.
- Laboratory cover:It uses a 5mm thick transparent imported high toughness PVC board, bending method designed to cover 100 degree ridge-type transparent
- With power failure memory function of time, so after the original call time to complete the remaining time of the experimental work, with a double over-temperature protection, water shortage warning, ensure safety
- Technical basis:According to JIS, ASTM, CNS, GB standard parameter setting operation.
| Standard | Laboratory | Air pressure barrel | |
| Salt spray test | NSS ,ACSS | 35°C±1°C | 47°C±1°C |
| Corrosion test | CASS | 50°C±1°C | 63°C±1°C |
Technical parameter of CX-60L
Model |
CX-60L Salt spray test tchambers |
Inner Box Size (L×W×H) |
60×40×45 cm |
Outside Box Size(L×W×H) |
107×60×118 cm |
Equipment Material |
Both inside & outside shell adopt imported P.V.C rigid plastic board, and tank cover uses imported transparent P.V.C. rigid plastic board |
Temperature Range |
35°C~55°C |
Temperature Fluctuations |
≤±0.5°C |
Temperature Uniformity |
≤±2°C |
Temperature Precision |
±1°C |
Test Chamber Temperature |
Salt Spray Method (NSS ACSS)35±1°C |
Saturated air Barrel Temperature |
Salt Spray Method (NSS ACSS)47±1°C |
Brine Temperature |
35°C±1°C |
Spray Quantity |
1.0~2.0 ml / 80cm2 / hr |
PH |
Salt Spray Method (NSS ACSS6.5~7.2) |
Lab Volume |
108L |
Brine Tank Capacity |
15L |
Power |
AC220V,10A |
Multiple Safety Protection Devices |
Current discharge protection, over pressure protection,over temperature protection, over load fuse protection |
Accessories |
Testing Salt/ Measuring tank/ Equipment each 1 set |
|
Salt Spray Resistance tester Standard |
CNS: 3627, 3385, 4159, 7669, 8886; |
3. Systems:
•Heating system
It uses steam heating, heating speed, reduce the standby time, when the temperature reached, the thermostat automatically switches the state, the temperature accuracy, less power consumption
•Control system
High-precision temperature controller, Japan OML timer to control the time, the overall temperature error of ± 1°c
