Maufactiromg Transformer Insulating Oil Dielectric Strength Tester With 80KV Output Voltage
US$ 2800.00 - 2800.00
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Chuangxin
Model Number:
CXYJ-501
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Manufacturing CX-K12 IEC60065 Figure 6 12KV Electric Safety Test EquipmentUS$ 200 - 500MOQ: 1 Set -
Megger Insulation Resistance Tester Made In ChinaUS$ 500 - 1,000MOQ: 1 Set
-
Programmable Hipot Tester/voltage Tester AC/DC 0~5kvUS$ 600 - 1,000MOQ: 1 Set
-
0-5kv Programmable AC Hipot And Insulation Resistance TesterUS$ 300 - 1,000MOQ: 1 Set
-
2672 AC 0~5kv High Voltage TesterUS$ 500 - 2,500MOQ: 1 Set
Place of Origin
Guangdong, China
Brand Name
Chuangxin
Model Number
CXYJ-501
Power
Electronic
Usage
Other, Insulating Oil Testing
Insulating Oil Tester (Transformer Oil Tester, Transformer Oil Dielectric Strength Tester)
Insulating Oil Tester is designed according to <Insulating Oil Dielectric Strength Test> of GB-86 and IEC60156 standards.
Parameters:
Model No |
CXYJ-501 |
CXYJ-502 |
CXYJ-503 |
Input Voltage |
AC 220V |
||
Output Voltage |
AC 0-80KV |
AC 100KV |
AC 0-80KV |
Standard |
GB-86/IEC60156 |
IEC60516/IS6792/BS5874/ASTMD18165/ASTMD18167/DL/T846.7-2004 |
GB-86/IEC60156 |
Oil Cup No. |
1pc |
1pc |
3pcs |
Rate of Voltage Rise |
2KV/s ±10% |
0.5kv/s±10% 2kv/s ±10% 3kv/s±10% 5kv/s±10% |
2KV/s ±10% |
Test Error |
<3%RDG +0.3%FS |
<3%RDG +0.3%FS |
<3%RDG +0.3%FS |
Max. Test Times |
9 |
9 |
9 |
Stir Time |
0-999s |
||
Wait time |
0-999s |
||
Storage |
100groups |
||
Environment Temperature |
5-40℃ |
||
Relative Humidity |
≤80%RH |
||
Dimension |
420x380x410mm |
630x400x300mm |
430x390x420mm |
Weight |
28KG |
41KG |
28KG |
